[admin@MikroTik] interface moxa-c101> monitor 0
dtr: yes
rts: yes
cts: yes
dsr: yes
dcd: yes
[admin@MikroTik] interface moxa-c101>

Troubleshooting

Description
• The synchronous interface does not show up under the interfaces list
Obtain the required license for synchronous feature
• The synchronous link does not work
Check the V.35 cabling and the line between the modems. Read the modem manual

Synchronous Link Application Examples

MikroTik Router to MikroTik Router
Let us consider the following network setup with two MikroTik Routers connected to a leased line
with baseband modems:
The driver for MOXA C101 card should be loaded and the interface should be enabled according to
the instructions given above. The IP addresses assigned to the synchronous interface should be as
follows:
[admin@MikroTik] ip address> add address 1.1.1.1/32 interface wan \
\... network 1.1.1.2 broadcast 255.255.255.255
[admin@MikroTik] ip address> print
Flags: X - disabled, I - invalid, D - dynamic
# ADDRESS
0 10.0.0.254/24
1 192.168.0.254/24
2 1.1.1.1/32
[admin@MikroTik] ip address> /ping 1.1.1.2
1.1.1.2 64 byte pong: ttl=255 time=31 ms
1.1.1.2 64 byte pong: ttl=255 time=26 ms
1.1.1.2 64 byte pong: ttl=255 time=26 ms
3 packets transmitted, 3 packets received, 0% packet loss
round-trip min/avg/max = 26/27.6/31 ms
[admin@MikroTik] ip address>
The default route should be set to the gateway router 1.1.1.2:
[admin@MikroTik] ip route> add gateway 1.1.1.2
[admin@MikroTik] ip route> print
Flags: X - disabled, I - invalid, D - dynamic, J - rejected,
C - connect, S - static, R - rip, O - ospf, B - bgp
# DST-ADDRESS
0 S 0.0.0.0/0
1 DC 10.0.0.0/24
2 DC 192.168.0.0/24
3 DC 1.1.1.2/32
[admin@MikroTik] ip route>
Page 220 of 695
Copyright 1999-2007, MikroTik. All rights reserved. Mikrotik, RouterOS and RouterBOARD are trademarks of Mikrotikls SIA.
Other trademarks and registred trademarks mentioned herein are properties of their respective owners.
NETWORK BROADCAST
10.0.0.254 10.0.0.255
192.168.0.254 192.168.0.255
1.1.1.2 255.255.255.255 wan
G GATEWAY
r 1.1.1.2
r 10.0.0.254
r 192.168.0.254
r 0.0.0.0
INTERFACE
ether2
ether1
DISTANCE INTERFACE
1 wan
1 ether2
0 ether1
0 wan
