IP addresses of DHCP-Relay:
[admin@DHCP-Relay] ip address> print
Flags: X - disabled, I - invalid, D - dynamic
# ADDRESS
0 192.168.0.1/24
1 192.168.1.1/24
2 192.168.2.1/24
[admin@DHCP-Relay] ip address>
To setup 2 DHCP Servers on DHCP-Server router add 2 pools. For networks 192.168.1.0/24 and
192.168.2.0:
/ip pool add name=Local1-Pool ranges=192.168.1.11-192.168.1.100
/ip pool add name=Local1-Pool ranges=192.168.2.11-192.168.2.100
[admin@DHCP-Server] ip pool> print
# NAME
0 Local1-Pool
1 Local2-Pool
[admin@DHCP-Server] ip pool>
Create DHCP Servers:
/ip dhcp-server add interface=To-DHCP-Relay relay=192.168.1.1 \
address-pool=Local1-Pool name=DHCP-1 disabled=no
/ip dhcp-server add interface=To-DHCP-Relay relay=192.168.2.1 \
address-pool=Local2-Pool name=DHCP-2 disabled=no
[admin@DHCP-Server] ip dhcp-server> print
Flags: X - disabled, I - invalid
# NAME
0 DHCP-1
1 DHCP-2
[admin@DHCP-Server] ip dhcp-server>
Configure respective networks:
/ip dhcp-server network add address=192.168.1.0/24 gateway=192.168.1.1 \
dns-server=159.148.60.20
/ip dhcp-server network add address=192.168.2.0/24 gateway=192.168.2.1 \
dns-server 159.148.60.20
[admin@DHCP-Server] ip dhcp-server network> print
# ADDRESS
0 192.168.1.0/24
1 192.168.2.0/24
[admin@DHCP-Server] ip dhcp-server network>
Configuration of DHCP-Server is done. Now let's configure DHCP-Relay:
/ip dhcp-relay add name=Local1-Relay interface=Local1 \
dhcp-server=192.168.0.1 local-address=192.168.1.1 disabled=no
/ip dhcp-relay add name=Local2-Relay interface=Local2 \
dhcp-server=192.168.0.1 local-address=192.168.2.1 disabled=no
[admin@DHCP-Relay] ip dhcp-relay> print
Flags: X - disabled, I - invalid
# NAME
0 Local1-Relay
1 Local2-Relay
[admin@DHCP-Relay] ip dhcp-relay>
IP Address assignment, using FreeRADIUS Server
Let us consider that we want to assign IP addresses for clients, using the RADIUS server.
Page 494 of 695
Copyright 1999-2007, MikroTik. All rights reserved. Mikrotik, RouterOS and RouterBOARD are trademarks of Mikrotikls SIA.
Other trademarks and registred trademarks mentioned herein are properties of their respective owners.
NETWORK
192.168.0.0
192.168.1.0
192.168.2.0
INTERFACE RELAY
To-DHCP-Relay 192.168.1.1
To-DHCP-Relay 192.168.2.1
GATEWAY
192.168.1.1
192.168.2.1
INTERFACE
Local1
Local2
BROADCAST
192.168.0.255
192.168.1.255
192.168.2.255
RANGES
192.168.1.11-192.168.1.100
192.168.2.11-192.168.2.100
ADDRESS-POOL LEASE-TIME ADD-ARP
Local1-Pool
Local2-Pool
DNS-SERVER WINS-SERVER
159.148.60.20
159.148.60.20
DHCP-SERVER
192.168.0.1
192.168.0.1
INTERFACE
To-DHCP-Server
Local1
Local2
3d00:00:00
3d00:00:00
DOMAIN
LOCAL-ADDRESS
192.168.1.1
192.168.2.1
