12. Enter the administrator password in the Security Check dialog box
OK to confirm the addition of the FCIP route.
Figure 53 FCIP Routes Add Wizard Security Check dialog box
.
The Add FCIP Route Completed message appears, signifying the completion of the route-add
operation.
13. Click OK to exit the dialog box.
Figure 54 FCIP Routes Add Wizard Completed dialog box
.

FCIP Route Remove

The FCIP Route Remove wizard provides step-by-step instructions for removing a FCIP route.
To remove an FCIP route:
1. When the FCIP Route Remove wizard is launched, a warning appears, cautioning that the
operation to be performed will change the operation of the selected GE and FC ports. Connectivity
on the GE port that is not part of the FCIP route being removed will be momentarily disrupted
(Figure 55).
If you want to proceed, click Yes and continue with step 2. Otherwise, click No to cancel the
wizard.
Figure 55 FCIP Routes Remove Confirm warning dialog box
.
(Figure 53), and then click
IP Distance Gateway User Guide 87
