5. Enter the IP addresses
Figure 50 FCIP Routes Add Wizard Local and Remote IP Address dialog box
.
6. Click Next to continue. Otherwise, click Cancel to exit the wizard.
7. Select either the IPv4 Address or IPv6 Address radio button.
IPv4 parameters include:
• Local IP Address The IP address to be used by the GigE port. An uninitialized port has an
IP address of all zeros.
• Subnet Mask
• Gateway IP Address The gateway IP address used by the GigE port.
• Remote IP Address The IP address of the GigE port on the remote gateway.
IPv6 parameters include:
• Local IPv6 Address The IP address assigned to the GigE port. An uninitialized port has an
IP address of "::".
• IPv6 Default Router The IP address assigned to the GigE port for the default IPv6 router. An
uninitialized port has an IP address of "::".
• IPv6 Local Link The IP address assigned to the Local Link port. This address is automatically
configured and is based on the GigE port MAC address. An uninitialized port has an IP ad-
dress of "::".
• Remote IPv6 Address The IP address assigned to the GigE port on the remote gateway. An
uninitialized port has an IP address of "::".
84 Using the HP StorageWorks mpx Manager utility
(Figure 50).
The subnet mask used by the GigE port.
