NOTE:
The 1U space in a rack includes three rail mounting holes; however, the rack holes are not
evenly spaced. For best installation the C-Shelf can be centered in a 1U space. To locate
the center, find a hole that is 5/8" on center from the hole immediately above and below.
The two holes above and below this center are only 1/2" on center from their adjacent
holes.
b. At the front of the rack, in the center mounting holes, install two nuts (KEPs 10-32, 0.375AF
CSZ EXT).
c. Carefully supporting the C-Shelf assembly, loosely thread the knurled thumbscrews through
the rack into the two nuts just installed.
d. Go to the back of the rack and position a slide bracket next to the corresponding holes at
the back of the rack. Slide the bracket to the rear until the threaded screw hole tabs are flush
with the inside of the rack rail.
e. Insert two screws (10-32 Pan 0.325 XRCS screws) through the rack rail into the threaded
screw hole tab and tighten loosely.
f. Repeat step e with the other side of the C-Shelf assembly.
g. Tighten all four screws (10-32 Pan 0.625 XRCS screws) at the rear of the C-Shelf assembly.
h. Tighten the front two knurled thumbscrews.
i. Tighten the two screws (10-32 Pan 0.625 XRCS screws) at each side of the back of the C-
Shelf assembly.
3. Install the mpx110 into one of the two available positions in the C-Shelf:
a. As the mpx110 slides in there are two tabs at the front and rear that catch and ensure that
the mpx110 is firmly seated to the C-Shelf assembly. Take care to ensure that the mpx110
is engaged in all four tabs. To ensure that all four of the tabs engage, you may need to hold
both the mpx110 and the C-Shelf assembly as you slide it in the last inch.
NOTE:
The front of the mpx110 is the end with the connections and faces the rear of the equipment
rack. The mpx110 slides in from the front of the equipment rack.
b. Once the rear of the mpx110 is flush with the front of the C-Shelf assembly and all four clips
are engaged, the bezel can be snapped on the front.

Installing the SFPs

You will need an SFP transceiver for each of the FC ports that connect to an FC switch.
To install the SFPs:
1. Align the SFP transceiver so that the key is oriented correctly to the port. Transceivers are keyed
so that they can only be inserted one way.
2. Insert the transceiver into the port.
3. Press gently until the transceiver snaps into place.
IP Distance Gateway User Guide 41
