Intel® Server Board S3000PT TPS

10. Hardware Monitoring

10.1

Monitored Components

The Intel® Server Board S3000PT has an SMsC* SCH5027 or SCH5017 Super IO controller
with integrated hardware monitoring function. It provides basic server hardware monitoring
which alerts a system administrator if a hardware problem occurs on the board. It also has
implemented some fan speed control/monitor pins. The following table provides a list of
monitored headers and sensors on the board.
Item
VCCP_IN (PIN #127)
Voltage
V1_IN (PIN #1)
V2_IN (PIN #2)
+2.5VTR_IN (PIN #128) Monitors 1.5V Core power
VBAT (PIN #32)
VTR1 (PIN #4)
HVTR (PIN #122)
PWM1 (PIN #111)
Fan Speed
PWM2 (PIN #110)
PWM3 (PIN #109)
TACH1 (PIN #115)
TACH2 (PIN #114)
TACH3 (PIN #113)
TACH4 (PIN #112)
TACHA (PIN #79)
TACHB (PIN #77)
Temperature
PECI (PIN #119)
REMOTE1N/P(PIN
#125/6)
REMOTE2N/P(PIN
#123/4)
1
Note: The SMsC* SCH5017 does not have a PECI interface.
78

Table 65. Monitored Components

Monitors processor voltage
Monitors +12Vin for system +12V supply
Monitors +5Vin for system +5V supply
Monitors Battery power
Monitors +3.3Vin for system +3.3V supply
Monitors +3.3V_STBY for system +3.3V standby supply
Controls system fan 3 (J4K1)
Controls system fan 2 (J4K2)
Controls system fan 1 (J3K1)
Monitors system fan 1 (J3K1)
Monitors system fan 3 (J4K1)
Monitors system fan 1 (J3K1)
Monitors system fan 2 (J4K2)
Monitors system fan 2 (J4K2)
Monitors system fan 3 (J4K1)
SMsC* SCH5027 or SCH5017 embedded temperature sensor
Monitors processor temperature through PECI interface
Monitors processor temperature
Monitors system inlet air temperature through sensor (Q4K3)
near FP connector
Hardware Monitoring
Description
1
Revision 1.3
