System BIOS
Setup Item
HyperThreading
Technology
Enhanced SpeedStep
Virtualization Technology
Execute Disable Bit
4.3.2.2.2 Memory Screen
The Memory screen provides a place for the user to view details about the system memory
DIMMs that are installed. On this screen, the user can select an option to open the Configure
Memory RAS and Performance screen.
To access this screen from the Main screen, select Advanced | Memory.
Advanced
Memory
Total Memory
Current Memory Configuration
Memory Channel A Slot
Memory Channel A Slot
Memory Channel B Slot
Memory Channel B Slot
Memory Correction
Figure 9. Setup Utility — Memory Configuration Screen Display
32
Options
Enable Enables or disables Intel® Hyper-
Threading Technology on the
Disable
processors. Select Disabled if your
operation system is Microsoft Windows
2000*.
Enable Enhanced Intel
Technology. Select Enable to allow the
Disable
OS to reduce power consum ption.
Enable When enabled, a Virtual Machine
Monitor can utilize the additional
Disable
hardware capabilities provided by Intel
Virtualization Technology
Enable
Execute Disable Bit featu re (XD bit).
Select Enabled to prevent data pages
Disable
from being used by malicious software
to execute code.
<Total Physical Memory Installed in Syst em>
<Single Channel/Dual Channel >
Not Installed/ Size Info
Not Installed/ Size Info
Not Installed/ Size Info
Not Installed/ Size Info
ECC/Non-ECC
Intel® Server Board S3000PT TPS
Help Text
®
SpeedStep
®
Comment
Displayed only when the
processor has the VT
function.
Revision 1.3
