- Page 1 ® Intel Entry Server Board SE7210TP1-E User Guide Order Number: C49109-002...
- Page 2 Intel’s own chassis are designed and tested to meet the intended thermal requirements of these components when the fully integrated system is used together. It is the responsibility of the system integrator that chooses not to use Intel developed server building blocks to consult vendor datasheets and operating parameters to determine the amount of airflow required for their specific application and environmental conditions.
-
Page 3: About This Manual
Processor, memory DIMMs, hard drive, floppy drive, CDROM or DVDROM drive, RAID controller, operating system. For information about which accessories, memory, processors, and third-party hardware have been tested and can be used with your board, and for ordering information for Intel products, see http://www.support.intel.com/support/motherboards/server/SE7210TP1-E/compat.htm. -
Page 4: Additional Information And Software
Chassis that have been tested with this product Processors that have been tested with this product DIMMs that have been tested with this product Power budget for this product Software to manage your Intel Server Diagnostics testing software Firmware and BIOS updates System drivers... -
Page 5: Warnings
To ensure EMC compliance with your local regional rules and regulations, the final configuration of your end system product may require additional EMC compliance testing. For more information please contact your local Intel Representative. See “Error! Hyperlink reference not valid.” for product Safety and EMC regulatory compliance information. - Page 6 Safety Cautions Read all caution and safety statements in this document before performing any of the instructions. See also Intel Server Boards and Server Chassis Safety Information on the Resource CD and/or at http://www.support.intel.com/support/motherboards/server/SE7210TP1-E. Wichtige Sicherheitshinweise Lesen Sie zunächst sämtliche Warn- und Sicherheitshinweise in diesem Dokument, bevor Sie eine...
-
Page 7: Table Of Contents
Contents Contents Warnings ......................v 1 Server Board Features................. 11 Server Board Connector and Component Locations ............13 Internal Component Connections..................14 Configuration Jumpers ......................15 Back Panel Connectors......................16 Hardware Requirements ....................... 17 2 Server Board Installations and Upgrades..........19 Before You Begin ........................ - Page 8 FCC (USA) ........................45 Industry Canada (ICES-003) ..................46 Europe (CE Declaration of Conformity)................ 46 Taiwan Declaration of Conformity ................46 Korean RRL Compliance....................47 Australia / New Zealand ....................47 Getting Help ....................... 48 ® Intel Server Issue Report Form............... 49 viii...
- Page 9 ® Figure 1. Intel Server Board SE7210TP1-E................. 11 Figure 2. Intel Server Board SE7210TP1-E Layout .............. 13 Figure 3. Making Connections to the Server Board .............. 14 Figure 4. Configuration Jumper Location ................15 Figure 5. Back Panel Connectors ..................16 Figure 6.
- Page 10 Contents...
-
Page 11: Server Board Features
Server Board Features Server Board Features ® This chapter briefly describes the main features of Intel Server Board SE7210TP1-E. This chapter provides a photograph of the product, a list of the server board features, and diagrams showing the location of important components and connections on the server board. This server board is... -
Page 12: Table 1. Server Board Features
Support for up to 4 GB Unbuffered ECC system memory Support for single-sided or double-sided DIMMs (DDR266/333/400) To run DDR400 memory at full speed requires an Intel Pentium 4 processor with 800 MHz system bus frequency. To run DDR333 memory at full speed requires an Intel Pentium 4 processor with 533 MHz system bus frequency. -
Page 13: Server Board Connector And Component Locations
P: Secondary IDE Connector II: Video Connector Q: Primary IDE Connector JJ: Serial A Connector R: Floppy Connector KK: Keyboard and Mouse S: Battery LL: USB Connectors Figure 2. Intel Server Board SE7210TP1-E Layout Intel Server Board SE7210TP1-E User Guide... -
Page 14: Internal Component Connections
P: Chassis Intrusion Header G: Main Power Connector Q: IDE Connectors H: Floppy Connector R: System Fan Header 4 I: Front Panel Connector S: System Fan Header 3 J: Hot-swap Backplane Headers T: Serial B Header Intel Server Board SE7210TP1-E User Guide... -
Page 15: Configuration Jumpers
BIOS code into the flash device from a floppy disk. This jumper is typically only used when the BIOS has become corrupted. These pins should be jumpered on 13-14 for normal operation. Intel Server Board SE7210TP1-E User Guide... -
Page 16: Back Panel Connectors
Left LED Solid Amber Network connection in place Blinking Amber Transmit/receive activity 10 Mbps connection (if left LED is on or blinking) Right LED Solid Amber 100 Mbps connection Solid Green 1000 Mbps connection Intel Server Board SE7210TP1-E User Guide... -
Page 17: Hardware Requirements
For a list of qualified components see the links under “Additional Information and Software.” Processor A minimum of one 2.0 GHz Intel Pentium 4 processor with 512KB cache support is required. For a complete list of supported processors, see the links under “Additional Information and Software.” Memory A minimum of one 128 MB Unbuffered, ECC or non-ECC, DDR266-, DDR333- or DDR400- compliant, 184-pin DIMMs. - Page 18 Server Board Features Intel Server Board SE7210TP1-E User Guide...
-
Page 19: Server Board Installations And Upgrades
1. Observe the safety and ESD precautions at the beginning of this book. 2. Turn off all peripheral devices connected to the server. Turn off the server. 3. Disconnect the AC power cord. 4. Remove the chassis cover and locate the DIMM sockets (see Figure 6). Intel Server Board SE7210TP1-E User Guide... -
Page 20: Removing Dimms
6. Hold the DIMM by the edges, lift it away from the socket, and store it in an anti-static package. 7. Reinstall and reconnect any parts you removed or disconnected to reach the DIMM sockets. 8. Replace the server’s cover and reconnect the AC power cord. Intel Server Board SE7210TP1-E User Guide... -
Page 21: Installing Or Replacing The Processor
TP00519 Figure 7. Installing the Processor in the Processor Socket NOTE The bottom of the heat sink may have thermal interface material (TIM) already applied. Be careful not to damage the thermal interface material. Intel Server Board SE7210TP1-E User Guide... -
Page 22: Figure 8. Attaching The Heat Sink To The Processor
8. With the levers in their fully opened position, push down firmly to secure the retention mechanism clips, represented by letter “B” in Figure 9. TP00521 Figure 9. Attaching the Fan Heat Sink Clips to the Processor Socket Intel Server Board SE7210TP1-E User Guide... -
Page 23: Figure 10. Attaching The Fan Heat Sink Clips To The Processor Socket
Figure 10. Attaching the Fan Heat Sink Clips to the Processor Socket 10. Connect the processor fan cable to the processor fan connector. See Figure 11. TP00523 Figure 11. Connecting the Processor Fan Cable to the Processor Fan Connector Intel Server Board SE7210TP1-E User Guide... -
Page 24: Removing The Processor
Discard used batteries according to manufacturer’s instructions. ADVARSEL! Lithiumbatteri - Eksplosionsfare ved fejlagtig håndtering. Udskiftning må kun ske med batteri af samme fabrikat og type. Levér det brugte batteri tilbage til leverandøren. Intel Server Board SE7210TP1-E User Guide... -
Page 25: Figure 12. Replacing The Battery
5. Insert the tip of a small flat bladed screwdriver, or an equivalent, under the tab in the plastic retainer. Gently push down on the screwdriver to lift the battery. 6. Remove the battery from its socket. TP00511 Figure 12. Replacing the Battery Intel Server Board SE7210TP1-E User Guide... - Page 26 8. Remove the new lithium battery from its package, and, being careful to observe the correct polarity, insert it in the battery socket. 9. Close the chassis. 10. Run Setup to restore the configuration settings to the RTC. Intel Server Board SE7210TP1-E User Guide...
-
Page 27: Server Utilities
If “Yes” is selected and the Enter key is pressed, all changes are saved and Setup is exited. If “No” is selected and the Enter key is pressed, or the ESC key is pressed, the user is returned to where they were before F10 was pressed without affecting any existing values. Intel Server Board SE7210TP1-E User Guide... -
Page 28: Upgrading The Bios
BIOS upgrade. Review also any release notes in the release notes file that accompanies the new version of the BIOS. The release notes may contain critical information regarding jumper settings, specific fixes, or other information to complete the upgrade. Intel Server Board SE7210TP1-E User Guide... -
Page 29: Upgrading The Bios
8. In Setup, press the F9 and <Enter> to set the parameters back to default values. 9. Re-enter the values you wrote down at the beginning of this process. Press F10 and <Enter> to exit BIOS Setup and Save Changes. Intel Server Board SE7210TP1-E User Guide... -
Page 30: Changing The Bios Language
You can use the BIOS upgrade utility to change the language the BIOS uses for messages and the Setup program. Use a bootable diskette containing the Intel flash utility and language files. 1. Boot the computer with the bootable diskette in drive A. The BIOS upgrade utility screen appears. -
Page 31: Clearing The Password
5. When the system begins beeping, power it down and disconnect the AC power. 6. Return the CMOS Clear jumper to the original location, covering pins 1 and 2. 7. Close the server chassis, reconnect the AC power and power up the system. Intel Server Board SE7210TP1-E User Guide... -
Page 32: Troubleshooting
SCSI drivers. Intel provides a package called the “Platform Confidence Test” that may help with your diagnostics. See “Additional Information and... -
Page 33: Hardware Diagnostic Testing
Does the diskette drive activity light turn on briefly? If not, see “Diskette Drive Activity Light Does Not Light.” If system LEDs are illuminated, see “LED Information” for a description of the light and steps to take to correct the problem. Intel Server Board SE7210TP1-E User Guide... -
Page 34: Confirming Loading Of The Operating System
Remove the processor(s) and re-seat them. Make sure the chassis standoffs are installed only below mounting holes. Misplaced standoffs can contact the pins on the bottom of the server board and cause a short. Intel Server Board SE7210TP1-E User Guide... -
Page 35: No Characters Appear On Screen
Are the brightness and contrast controls properly adjusted on the video monitor? See the manufacturer’s documentation. Are the video monitor’s signal and power cables properly installed? Does this video monitor work correctly if plugged into a different system? Intel Server Board SE7210TP1-E User Guide... -
Page 36: System Cooling Fans Do Not Rotate Properly
CD-ROM Drive or DVD-ROM Drive Activity Light Does Not Light Check the following: Are the CD-ROM/DVD-ROM drive’s power and signal cables properly installed? Are all relevant switches and jumpers on the drive set correctly? Is the drive properly configured? Intel Server Board SE7210TP1-E User Guide... -
Page 37: Cannot Connect To A Server
The add-in adapter stopped working without apparent cause. Try reseating the adapter first; then try a different slot if necessary. The network driver files may be corrupt or deleted. Delete and then reinstall the drivers. Run the diagnostics. Intel Server Board SE7210TP1-E User Guide... -
Page 38: System Boots When Installing Pci Card
If you suspect that a transient voltage spike, power outage, or brownout might have occurred, reload the software and try running it again. Symptoms of voltage spikes include a flickering video display, unexpected system reboots, and the system not responding to user commands. Intel Server Board SE7210TP1-E User Guide... -
Page 39: Devices Are Not Recognized Under Device Manager (Windows* Operating System)
Devices are not Recognized under Device Manager (Windows* Operating System) The Windows* operating systems do not include all of the drivers for the Intel® chipsets, onboard NICs, and other components. See “Additional Information and Software”... -
Page 40: Led Information
Off = Power is off (off or Power LED Identify the power state Front Panel Green of the system On = Power on or S0) Slow Blink = Low power state (S1 – S3) Intel Server Board SE7210TP1-E User Guide... -
Page 41: Bios Error Messages
No Boot Device Available System did not find a device to boot. Off Board Parity Error A parity error occurred on an off-board card. This error is followed by an address. continued Intel Server Board SE7210TP1-E User Guide... -
Page 42: Bios Post Beep Codes
Invalid BIOS (such as, POST module not found) BIOS Recovery Beep Codes Table 7. BIOS Recovery Beep Codes Number of Beeps Reason One long beep – video is active. One long beep and two short beeps: Insert the BIOS recovery diskette. Intel Server Board SE7210TP1-E User Guide... - Page 43 An error or warning condition at boot can result in a series of beeps being issued known as "beep ® codes. These beeps have a code that identifies system or PCI card events. For example, some Intel RAID cards have beep codes. Before checking for a system beep code error make sure the PCI card is not causing the beeping.
-
Page 44: Regulatory And Compliance Information
(EMC) regulations when installed a compatible Intel host system. For information on compatible host system(s) refer to Intel’s Server Builder Web site or contact your local Intel representative. FCC (Class A Verification) – Radiated & Conducted Emissions (USA) ICES-003 (Class A) –... -
Page 45: Product Regulatory Compliance Markings
(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. For questions related to the EMC performance of this product, contact: Intel Corporation 5200 N.E. Elam Young Parkway Hillsboro, OR 97124 1-800-628-8686 Intel Server Board SE7210TP1-E User Guide... -
Page 46: Industry Canada (Ices-003)
(73/23/EEC) and EMC Directive (89/336/EEC). The product has been marked with the CE Mark to illustrate its compliance. Taiwan Declaration of Conformity This product has been tested and complies with CNS13438. The product has been marked with the BSMI DOC mark to illustrate compliance. Intel Server Board SE7210TP1-E User Guide... -
Page 47: Korean Rrl Compliance
MIC logo to illustrate compliance. The English translation for the above is as follows: 1. Type of Equipment (Model Name): SE7210TP1-E 2. Certification No.: Contact Intel Representative 3. Name of Certification Recipient: Intel 4. Date of Manufacturer: Marked on Product 5. -
Page 48: Getting Help
Telephone All calls are billed US $25.00 per incident, levied in local currency at the applicable credit card exchange rate plus applicable taxes. (Intel reserves the right to change the pricing for telephone support at any time without notice). Before calling, fill out an “Intel®... -
Page 49: Intel Server Issue Report Form
DIMM1B MB: System BIOS Version: DIMM1B Vendor/part number: HSC Firmware Version: DIMM2A MB: Chassis Model DIMM2A Vendor/part number: Intel SC5200 Base Redundant Power DIMM2B MB: Intel SC5250-E DIMM2B Vendor/part number: Other (Vendor / Model): Intel Server Board SE7210TP1-E User Guide... - Page 50 On-Board Video Add-in Video On-Board NIC1 (1.0 Gb) On-Board NIC2 (10/100 Mb) Hard Drive Information: # of drives installed: Make/Model/Firmware Revision SCSI # of drives installed: Make/Model/Firmware Revision SATA # of drives installed: Make/Model/Firmware Revision Intel Server Board SE7210TP1-E User Guide...
- Page 51 In the space below, provide a complete description of the steps used to reproduce the problem or a complete description of where the problem can be found. Please also include any details on troubleshooting already done. Intel Server Board SE7210TP1-E User Guide...
