4.3.2.2.5 USB Controller Screen
Advanced
USB Function
Module Version
USB Devices Enabled:
<Total USB Devices in System>
USB Controller
Legacy USB Support
Port 60/64 Emulation
USB Mass Storage Device
USB 2.0 Controller
USB Mass Storage Emulation
Generic USB Flash Drive
Figure 12. Setup Utility — USB Controller Configuration Screen Display
Table 23. Setup Utility — USB Controller Configuration Screen Fields
Setup Item Option
Module Version
USB Devices
Enabled:
USB Controller
Enabled
Disabled
Legacy USB Enabled
Support
Disabled
Auto
Port 60/64 Enabled /
Emulation
Disabled
USB 2.0
Enabled
Controller
Disabled
36
08.04.02
Enabled / Disabled
Enabled / Disabled / Auto
Enabled / Disabled
Enabled / Disabled /Auto
Enabled / Disabled
Auto / Floppy / Forced FDD / Hard Disk / CD -ROM
Help Text
USB Driver version
shows number of USB devices in Syste m
If Disabled, all of the USB controllers will be
turned off and inaccessable by the OS.
Enables Legacy USB support. Auto option
disables legacy support if no USB devices are
connected.
Enables I/O Port 60h/64h emulation support.
This should be enabled for the complete USB
keyboard Legacy support for non-USB aware
operating systems.
If Disabled, all of the USB 2.0 controller will be
turned off and inaccessable by the OS.
Intel® Server Board S3000PT TPS
Comment
Information only
Information only
Revision 1.3
