Server Board Overview

2. Server Board Overview
The Intel® Server Board S3000PT is a monolithic printed circuit board with features that
support the UP server market.
2.1 Intel® Server Board S3000PT Feature Set
The Intel® Server Board S3000PT supports the following feature set:
Processor and Front Side Bus (FSB) support
-
Supports Intel® Xeon® processor 3000 sequence, Intel® Core™2 Extreme Edition,
Intel® Core™2 Duo, Intel® Pentium® Processor Extreme Edition,Intel® Pentium® D
Processor,Intel® Pentium® 4 Processor, Intel® Celeron® D Processor in the Intel®
LGA775 package
-
Supports Intel® Dual Core Architecture
-
Supports Hyper-Threading Technology
-
Supports Intel® Extended Memory System 64 Technology (Intel® EM64T)
Intel® 3000 Chipset components
-
Intel® 3000 MCH Memory Controller Hub
-
Intel® ICH7R I/O Controller
-
12-deep In-order Queue
Memory System
-
Four DIMM sockets supporting DDR2 533/667MHz DIMMs
-
Data bandwidth per channel of 4.2GB/s or 8.4GB/s in dual channel when using
DDR2 667MHz
-
Support for up to two DDR2 channels for a total of four DIMMs (2 DIMMs / c hannel)
providing up to 8-GB max memory capacity.
-
Support for 512-MB, 1-GB and 2-GB DRAM modules
I/O Subsystem
Board I/O Subsystem:
-
Segment A: One embedded ATI* ES1000 video controller (Supports PCI
Specification, Rev 2.3).
-
Segment B: One x1 PCI Express* resource implemented as an embedded Intel®
82573V 10/100/1000 gigabit Ethernet Controller
-
Segment C: One x1 PCI Express* resource implemented as an embedded Intel®
82573E 10/100/1000 gigabit Ethernet Controller
-
Segment D: One x8 PCI Express* resource implemented as a riser slot supporting
single x1/x4/x8 PCI Express* add-in cards through a riser
Serial ATA host controller
Two independent SATA ports suppo rt data transfer rates up to 3.0 Gb/s (300MB/s) per
port
Universal Serial Bus 2.0 (USB)
