System BIOS
Console Redirection
Console Redirection
Flow Control
Baud Rate
Terminal Type
Figure 20. Setup Utility — Console Redirection Screen Display
Table 29. Setup Utility — Console Redirection Configuration Fields
Setup Item
Console Redirection
Disabled
Enabled
Flow Control
None
RTS/CTS
Baud Rate
9.6K
19.2K
36.4K
57.6K
115.2K
Terminal Type
VT100
VT100+
VT-UTF8
PC-ANSI
44
Management
Disabled / Enabled
None - RTS/CTS -
9.6k / 19.2k / 38.4k / 57.6k / 115.2k
PC-ANSI / VT100 / VT100+ / VT-UTF8
Option
Intel® Server Board S3000PT TPS
Server
Help Text
Enables and disables the ability
of the system to redirect screen
data across a serial connection.
Sets the handshake protocol the
BIOS should expect from the
remote console redirection
application.
Sets the communication speed
for the redirection data.
Sets the character formatting for
the console redirection screen .
Comment
Revision 1.3
