Intel® Server Board S3000PT
4.3.1.2 Entering BIOS Setup
BIOS Setup is started by pressing <F2> during boot time when the OEM or Intel logo is
displayed.
When Quiet Boot is disabled, there will be a message "press <F2> to enter setup" displayed on
the diagnostics screen.
4.3.1.3 Keyboard Commands
The bottom right portion of the Setup screen provides a list of commands that are used to
navigate through the Setup utility. These c ommands are displayed at all times.
Each Setup menu page contains a number of features. Except those used for informative
purposes, each feature is associated with a value field. This field contains user -selectable
parameters. Depending on the security opt ion chosen and in effect by the password, a menu
feature's value may or may not be changeable. If a value is non -changeable, the feature's value
field is inaccessible. It displays as "grayed out."
The Keyboard Command Bar supports the following:
Key Option
<Enter> Execute
Command
<Esc> Exit
Select Item
Select Item
Select Menu
<Tab> Select Field
- Change Value
Revision 1.3

Table 17. BIOS Setup: Keyboard Command Bar

The <Enter> key is used to activate sub -menus when the selected feature is a
sub-menu, or to display a pick list if a selected option has a value field , or to select
a sub-field for multi-valued features like time and date. If a pick list is displayed,
the <Enter> key will select the currently highlighted item, undo the pick list, and
return the focus to the parent menu.
The <Esc> key provide s a mechanism for backing out of any field. This key will
undo the pressing of the Enter key. When the <Esc> key is pressed while editing
any field or selecting features of a menu, the parent menu is re -entered.
When the <Esc> key is pressed in any sub -menu, the parent menu is re -entered.
When the <Esc> key is pressed in any major menu, the exit confirmation window
is displayed and the user is asked whether changes can be discarded. If "No" is
selected and the <Enter> key is pressed, or if the <Esc> key is pressed, the user
is returned to where he/she was before <Esc> was pressed, without affecting any
existing any settings. If "Yes" is selected and the <Enter> key is pressed, setup is
exited and the BIOS returns to the main System Options Menu screen.
The up arrow is used to select the previous value in a pick list, or the previous
option in a menu item's option list. The selected item must then be activated by
pressing the <Enter> key.
The down arrow is used to select the next value in a menu item's option list, or a
value field's pick list. The selected item must then be activated by pressing the
<Enter> key.
The left and right arrow keys are used to move between the major menu pages.
The keys have no affect if a sub-menu or pick list is displayed.
The <Tab> key is used to move between fields. For example, <Tab> can be used
to move from hours to minutes in the time item in the main menu.
The minus key on the keypad is used to c hange the value of the current item to the
previous value. This key scrolls through the values in the associated pick list
without displaying the full list.
Description
System BIOS
27
