Intel® Server Board S3000PT
Table 26. Setup Utility — System Acoustic and Performance Configuration Screen Fields
Setup Item
NumLock
On
Off
4.3.2.2.8 Hardware Health Configuration
The Hardware Health Configuration screen provides for configuration and display of the
hardware monitor.
To access this screen from the Main screen, select Advanced | Hardware Health Configuration .
Advanced
►Hardware Monitor
Auto Fan Control
Figure 16. Setup Utility — Hardware Health Configuration Screen Display
Setup Item
Hardware Monitor
Auto Fan Control
Enabled / Disabled
Revision 1.3
Option
Enabled / Disabled
Option
Help Text
Turns keyboard NumLock on or
off.
Help Text
View the Hardware Monitor
information.
Enable / disable auto fan
control. If enabled, fan speed
will be adjusted automatically
according to the temperature; if
disabled, all fans will run at full
speed.
System BIOS
Comment
System boot
with NumLock
default setting
to ON or OFF.
Comment
39
