System BIOS
Key Option
+ Change Value
<F9> Setup Defaults
<F10> Save and Exit
4.3.1.4 Menu Selection Bar
The Menu Selection Bar is located at the top of the scr een. It displays the major menu
selections available to the user.
4.3.2

Server Platform Setup Screens

The following sections describe the screens available for the configuration of a server platform.
In these sections, tables are used to describe the contents of each screen. These tables follow
the following guidelines:
The text and values in the Setup Item, Options, and Help columns in the tables are
displayed on the BIOS Setup screens.
Bold text in the Options column of the tables indicates default values. The se values are
not displayed in bold on the setup screen. The bold text in this document is to serve as a
reference point.
The Comments column provides additional information where it may be helpful. This
information does not appear in the BIOS Setup screen s.
Information in the screen shots that is enclosed in brackets (< >) indicates text that
varies, depending on the option(s) installed. For example <Current Date> is replaced by
the actual current date.
Information that is enclosed in square brackets ([ ]) in the tables indicates areas where
the user needs to type in text instead of selecting from a provided option.
28
The plus key on the keypad is used to change the value of the current menu item
to the next value. This key scrolls through the values in the associated pick list
without displaying the full list. On 106 -key Japanese keyboards, the plus key has a
different scan code than the plus key on the other keyboard, but will have the
same effect.
Pressing <F9> causes the following to appear:
Load Optimized defaults? (Y/N)
If the <Y> key is pressed, all Setup fields are set to their default values. If the <N>
key is pressed, or if the <Esc> key is pressed, the user is retur ned to where they
were before <F9> was pressed without affecting any existing field values
Pressing <F10> causes the following message to appear:
Save Configuration and Reset? (Y/N)
If the <Y> key is pressed, all changes are saved a nd Setup is exited. If the <N>
key is pressed, or the <Esc> key is pressed, the user is returned to where they
were before <F10> was pressed without affecting any existing values.
Intel® Server Board S3000PT TPS
Description
Revision 1.3
