Intel® Server Board S3000PT TPS
Diagnostic LED Decoder
Checkpoint
G=Green, R=Red, A=Amber
MSB
0xE1h R R
0xE2h R R
0xE3h R R
Driver eXecution Environment (DXE) Core
0xE4h R A
0xE5h R A
0xE6h R A
0xEBh A R
0xECh R A
DXE Drivers
0xE7h R A
0xE8h A R
0xE9h A R
0xEAh A R
0xEEh A A
0xEFh A A
Runtime Phase / EFI Operating System Boot
0xF4h R A
0xF5h R A
0xF8h
A R
0xF9h
A R
0xFAh
A R
Pre-EFI Initialization Module (P EIM) / Recovery
0x30h OFF OFF
0x31h OFF OFF
0x34h OFF G
0x35h OFF G
0x3Fh G G
6.2.3

POST Error Messages and Handling

Whenever possible, the BIOS will output the current boot progress codes on the video screen.
Progress codes are 32-bit quantities plus optional data. The 32-bit numbers include class,
subclass, and operation information. The class and subclass fields point to the type of hardware
that is being initialized. The operation field represents the specific initialization activity. Based
on the data bit availability to display progress codes, a progress code can be customized to fit
the data width. The higher the data bit, the higher the granularity of information that can be sent
on the progress port. The progress codes may be reported by the system BIOS or option
ROMs.
The Response column in the following table is divided into two types:
62
LSB
R G Completed dispatching an PEIM
A OFF Initial memory found, configured, and installed correctly
A G Reserved for initialization module u se (PEIM)
R OFF Entered EFI driver execution phase (DXE)
R G Reserved for DXE core use
A OFF Started connecting drivers
A G Started dispatching a driver
A OFF Completed dispatching a driver
A G Waiting for user input
R OFF Checking password
R G Entering BIOS setup
A OFF Flash Update
A OFF Calling Int 19. One beep unless silent boot is enabled.
A G Reserved for DXE Drivers use
R R Entering Sleep state
R A Exiting Sleep state
Operating system has requested EFI to close boot services
R R
(ExitBootServices ( ) has b een called)
Operating system has switched to virtual address mode
R A
(SetVirtualAddressMap ( ) has been called)
Operating system has requested the system to reset (ResetSystem ()
A R
has been called)
R R Crisis recovery has been initiated because of a user request
R A Crisis recovery has been initiated by software (corrupt flash)
R R Loading crisis recovery capsule
R A Handing off control to the crisis recovery capsule
A A Unable to complete crisis recovery.
Error Reporting and Handling
Description
Revision 1.3
