Connectors and Jumper Blocks
Name
Normal
CMOS Clear

Table 59. NIC1 Firmware Update Jumper Options (J1B2)

Name
Normal
Recover

Table 60. System Maintenance Mode Jumper Options (J1B3)

Name
Normal
Maintenance Mode
Revision 1.3
Pin – Pin Function
1-2 Normal operation
2-3 Clears CMOS (NVRAM)
Pin – Pin Function
1-2 Normal operation
Disable NIC1 firmware upda te
2-3
protection
Pin – Pin Function
1-2 Normal Operation
2-3 Maintenance Mode
Intel® Server Board S3000PT TPS
Description
Jumper in normal position allows system to
successfully POST and boot to operating
system environment. BIOS settings are
maintained intact.
Jumper in CLEAR position initiates clear of
NVRAM following POST. System message
confirms success of CMOS clear operation.
This setting enforces default BIOS settings,
which can be changed by entering setup via
F2, then exiting setup via F10 and saving
changes.
Description
Jumper in normal position allows system to
successfully POST and boot to operating
system environment. BIOS settings are
maintained intact.
Jumper in Recover position disables NVRAM
protection of NIC1. It allows the user to
update Intel® AMT firmware for NIC1.
Description
Allows normal system operation with correct
BIOS settings. System will POST normally.
®
Intel AMT setting/password reset .
