- Page 1 SBC-776 Full-sized Intel FC-370 Pentium III CPU Card with Intel 815E chipset, Dual LAN, Audio, SCSI, LCD & 4 USB.
-
Page 2: Copyright Notice
AAEON reserves the right to make changes in the product design without notice to its users. Part No. 2047776000 SBC-776 1st. Edition Printed in Taiwan May., 2001... - Page 3 Award is a trademark of Award Software International, Inc. IBM, PC/AT, PS/2, and VGA are trademarks of International Business Machines Corporation. Intel and Pentium III are trademarks of Intel Corporation. ® Microsoft Windows is a registered trademark of Microsoft Corp.
-
Page 4: Technical Support
A Message to the Customer AAEON Customer Services Each and every AAEON product is built to the most exacting specifications to ensure reliable performance in the harsh and demanding conditions typical of industrial environments. Whether your new AAEON equipment is destined for the laboratory or the factory floor, you can be assured that your product will provide the reliability and ease of operation for which the name AAEON has come to be known. -
Page 5: Product Warranty
Product Warranty AAEON warrants to you, the original purchaser, that each of its products will be free from defects in materials and workmanship for two years from the date of shipment. This warranty does not apply to any products which have been repaired or altered by persons other than repair personnel autho- rized by AAEON, or which have been subject to misuse, abuse, accident or improper installation. -
Page 6: Packing List
Packing list Before you begin installing your card, please make sure that the following materials have been shipped: • 1 SBC-776 Half- size Single Board Computer Card • 1 Quick Installation Guide • 1 Support CD contains the followings: -- User's Manual (this manual in PDF file) - Page 7 Dear Customer, Thank you for purchasing the SBC-776 board. This user's manual is designed to help you to get the most out of the SBC-776, please read it thoroughly before you install and use the board. The product that you have purchased comes with an two-year limited warranty, but AAEON will not be responsible for misuse of the product.
-
Page 8: Table Of Contents
Contents Chapter 1: General Information.........1 Introduction............2 Features ..................3 Specifications ................4 Board layout ................7 Board dimensions ..............8 Chapter 2: Installation ............9 Safety Precautions............10 Removing the CPU..........10 Installing the CPU............... 11 Installing SDRAM...........12 Jumpers..............13 Connectors ................14 Locating Jumpers and Connectors..........15 Mechanical Drawing..........17 VGA or AGP VGA Header Select (JP1).........19... - Page 9 COM1 & COM2 Serial Port (CN15, CN16)......35 SCSI Connector (CN21) ............36 100Base-Tx Fast Ethernet Connector (CN22, CN20) .... 37 ATX Power Connector (CN23)......38 Speaker/BuzzerConnector (CN24)......38 Fan Power Connector (CN25, CN26, CN27)......39 LCD Backlight Power Connector (CN28)....40 TFT LCD Panel Connector (CN29)......40 PS/2 Keyboard Header (CN31)......41 PS/2 Mouse Header (CN32)........41 Chapter 3: Award BIOS Setup...........
- Page 10 Chapter 4: Drivers and Utilities ........82 Installing Drivers Attention Notice........83 Software Installation Utilities........85 Intel 82562ET LAN Driver..........86 Advansys 38C0800 SCSI Driver..........89 Intel 82559ER LAN Driver...........91 Driver...............93 Ultra ATA Storage Driver..........94 Audio Driver............95...
-
Page 11: Chapter 1: General Information
General Information This chapter gives background information of the mainboard. Sections Include: • Board Specifications • Layout and Dimensions Chapter 1 General Information... -
Page 12: Introduction
Introduction The SBC-776 is an all-in-one Single Board Computer (SBC) capable of handling the Intel Celeron 300~766MHz (with system bus frequencies of 66MHz) and Pentium III 500~850 MHz (with system bus frequencies of 100MHz). Reliability, performance, flexibility are essential qualities for SBC's and SBC-776 offers all of these. -
Page 13: Features
• High Speed AGP 2X for VGA function onboard (Intel 815E built in) • Two 10/100 Base-T Fast Ethernet (Intel 815 E built in and Intel 82559ER) • Supports H/W status monitoring • Integrated AC-97 2.1 SoundBlaster compatible PCI 3D Audio •... -
Page 14: Specifications
Standard LPX-size SBC functions • CPU: FC-370 Pentium III (Coppermine), Celeron, and compatible CPUs (With system bus frequencies of 66/100/133MHz). • CPU socket: Intel Socket 370 • Bus interface: PICMG Compliant • BIOS: Award 4 MB Flash BIOS • Chipset: Intel 815E •... - Page 15 • Audio interface: One 14 pin header (2.00mm) • Codec: ALC 200 Ethernet Interface • Chipset: Intel 815E embedded in ICH2 and Intel 82559ER • Ethernet interface : 82559ER does not support WOL and AOL 82562ET support WOL and do not support AOL 82562EM support WOL and AOL.
- Page 16 • One 32-pin DIP socket supports M-Systems DiskOnChip 2000 series Mechanical and environmental • Power supply voltage: ATX power supply • Operating temperature: 32 to 140 F (0 to 60 • Board size: 13.3"(L) x 4.8"(W) (338mm x 122mm) • Weight: 1.2 lb. (0.3 Kg) SBC-776 User Manual...
-
Page 17: Board Layout
Board Layout CN24 JP10 CN12 CN28 CN29 CN30 W83977F-A CN10 inbond CN33 CN21 CN11 CN32 Chapter 1 General Information... -
Page 18: Board Dimensions
Board Dimensions W83977F-A inbond SBC-776 User Manual... -
Page 19: Chapter 2: Installation
This chapter describes how to set up the main board hardware, including instruc- tions on setting jumpers and connecting peripherals, switches, and indicators. Be sure to read all the safety precautions before you begin the installation proce- dure. SBC-776 Chapter 2... -
Page 20: Safety Precautions
Removing the CPU The SBC-776 all-in-one CPU module supports most Pentium III/ Celeron or 586 CPUs. The system's performance depends on the CPU you choose. You can install or upgrade the CPU in the board's PGA socket by following the procedures outlined below. -
Page 21: Installing The Cpu
When you install a new CPU, you may have to adjust other settings on the board, such as CPU type, CPU clock, and PCI speed, to accommodate it. Make sure that the settings are correct for your CPU. Improper settings may damage the CPU. SBC-776 Chapter 2... -
Page 22: Installing Sdram
SBC-776 Installing DRAM (DIMMs) System Memory The SBC-776 contains three sockets for 168-pin dual inline memory module (DIMM). The socket uses 3.3 V unbuffered synchronous DRAM (SDRAM). DIMM is available in capacities of 16, 32, 64, 128 or 256 MB. The socket can be filled in the DIMM of any size, giving your SBC-776 single board computer between 16 and 512 MB of memory. -
Page 23: Jumpers
VGA or AGP VGA Select Header Clear CMOS Selection Watchdog Function Select RS-232/422/485 COM 2 Setting DiskOnChip Address Selection Function Select CPU/DIMM Speed Select LCD Panel's Voltage Setting RS-232/422/485 COM2 Setting JP10 LCD or VGA Enable Header SBC-776 Chapter 2... -
Page 24: Connectors
ATX Power Supply CN24 Speaker/Buzzer CN25 System FAN 1 Connector CN26 CPU Fan Connector CN27 System FAN 2 Connector CN28 LCD Backlight Power Connector CN29 TFT LCD Panel Connector CN31 PS/2 Keyboard Header CN32 PS/2 Mouse Header BC-599/596 SBC-776 Manual... -
Page 25: Locating Jumpers And Connectors
Locating Jumpers and Connectors CN24 JP10 CN12 CN28 CN29 CN30 W83977F-A CN10 inbond CN33 CN21 CN11 CN32 SBC-776 Chapter 2... - Page 26 SBC-776 Locating Jumpers and Connectors BC-599/596 SBC-776 Manual...
-
Page 27: Mechanical Drawing
Mechanical Drawing W83977F-A inbond SBC-776 Chapter 2... - Page 28 SBC-776 Mechanical Drawing BC-599/596 SBC-776 Manual...
-
Page 29: Vga Or Agp Vga Header Select (Jp1)
You can use JP2 to clear the CMOS data if necessary. To reset the CMOS data, place a jumper on JP2 for just a few seconds, then remove the jumper. Clear CMOS (J2P) Clear CMOS Protect 1 2 3 1 2 3 *default SBC-776 Chapter 2... - Page 30 The mainboard is equipped with a watchdog timer that resets the CPU or generates an interrupt if processing comes to a standstill for whatever reason. This feature ensures system reliability in industrial stand-alone and unmanned environments. Reset IRQ15 BC-599/596 SBC-776 Manual...
- Page 31 RS-232/422/485 COM 2 (JP4 & JP9) Setting The SBC-776 COM 2 serial port can be selected as RS-232/422/485 by setting JP4. *RS-232 3 6 9 12 2 4 6 1 3 5 1 4 7 10 *RS-485 3 6 9 12...
-
Page 32: Diskonchip Address Select (Jp5)
JP5 controls the memory address of the Flash Disk. *D400H 1 3 5 2 4 6 *DC00H 1 3 5 2 4 6 *CE00H 1 3 5 2 4 6 *D000H 1 3 5 2 4 6 BC-599/596 SBC-776 Manual... - Page 33 2 4 6 *D800H 1 3 5 2 4 6 *C800H 1 3 5 2 4 6 These addresses might conflict with the ROM BIOS of other peripheral boards, Please select the appropriate memory address to avoid memory conflicts. SBC-776 Chapter 2...
-
Page 34: Function Select Header (Jp6)
Speaker The mainboard can drive an 8 external speaker at 0.5 watts. If there is no external speaker, the SBC-776 provides an onboard buzzer as an alternative. LED interface The front panel LED indicator for hard disk access is an active low signal (24 mA sink rate). -
Page 35: Cpu/Dimm Speed Select Header (Jp7)
CPU/DIMM Speed Select Header (JP 7) CPU/133 DIMM/133 CPU/133 DIMM/100 CPU/100 DIMM/100 CPU/66 DIMM/100 SBC-776 Chapter 2... - Page 36 SBC-776 Auto Detect Default BC-599/596 SBC-776 Manual...
-
Page 37: Lcd Panel's Voltage Setting (Jp8)
*LCD Panel power: +5V; Backlight power: +12V 1 3 5 2 4 6 *LCD Panel power: +3.3V; Backlight power: +5V 1 3 5 2 4 6 *LCD Panel power: +3.3V; Backlight power: +12V 1 3 5 2 4 6 SBC-776 Chapter 2... -
Page 38: Lcd Or Vga Enable Header (Jp10)
CN6 is a 15-pin, dual-in-line header used for conventional CRT displays. A simple one-to-one adapter can be used to match CN6 to a standard 15-pin D-SUB connector commonly used for VGA. VGA display connector (CN6) Signal Signal GREEN BLUE DDDA H-SYNC V-SYNC DDCK BC-599/596 SBC-776 Manual... -
Page 39: Ide Hard Drive Connector (Cn7)
DATA 14 DATA 0 DATA 15 SIGNAL GND IDEPDREQR IO WRITE IO READ IO CHANNEL READY 28 IDEPDACKX IRQ14 IOCS16 ADDR 1 P66DET ADDR 0 ADDR 2 HARD DISK SELECT 0 HARD DISK SELECT 1 IDE ACTIVE MGND SBC-776 Chapter 2... -
Page 40: Usb Connector (Cn9, Cn10)
SBC-776 USB connector (CN9, CN10) The SBC-776 provides two USB (Universal Serial Bus) interfaces, which give complete plug and play, hot attach/detach for up to 127 external devices. The USB interfaces comply with USB specifica- tion Rev. 1.0, and can be disabled in the system BIOS setup. -
Page 41: Audio Connector (Cn11)
Audio Connector (CN11) On board SBC-776, there is a 14-pin header for audio capability. The pin definition is provided below. Audio connector (CN 11) Signal Signal MIC IN MIC VCC CD IN GND LINE IN L CD IN L I/P... -
Page 42: Floppy Drive Connector (Cn12)
READ DATA HEAD DELECT DISK CHANGE PS/2 Keyboard and Mouse Connector (CN13) On board SBC-776, there is a standard 6-pin header for PS/2 keyboard and mouse connector. The pin definition is provided below. Keyboard and mouse connector (CN 13) Signal... -
Page 43: Parallel Port Connector (Cn14)
Parallel port connector (CN14) Normally, the parallel port is used to connect the board to a printer. The SBC-776 includes an onboard parallel port, accessed through CN14, a 26-pin flat-cable connector. A traditional DB-25 connector cable is needed to install the printer to the board. The cable has a 26-pin connector on one end and a DB-25 connector on the other. - Page 44 Two of them are the D-Sub type, pin definition show as below, for another two, please refer to page ?. COM 1 RS-232 (CN15) Signal Signal SDCDB1X SDSRB1X SRXDB1 SRTSB1X STXDB1 SCTSB1X SDTRB1X SRIB1X COM 1 RS-232 (CN16) Signal Signal SDCDB2X SDSRB2X SRXDB2 SRTSB2X STXDB2 SCTSB2X SDTRB2X SRIB2X BC-599/596 SBC-776 Manual...
- Page 45 SCSI-2 68-PinConnector (CN 21) SBC-776 has a 68 pin connector for the Ultra 2 SCSI connection. Please pay attention when connecting the SCSI device, because you must determine the last device on the SCSI chain. FUNCTION FUNCTION SD+12 SD-12 SD+13...
- Page 46 The RJ-45 connector has two LED indicators. Both LED displays indicate the speed of information being processed, however the Lan speed does vary. * The on board Intel 82559XX fast ethernet controller supports 10Mb/s and 100Mb/s N-way auto-negotiation operation. Green LED: 100M LAN speed...
-
Page 47: Atx Power Connector (Cn23)
POWER ON +5 V POWER OK +5VSB +12V Speaker/Buzzer (CN 24) You can choose to use the internal buzzer on the SBC-776 baord, or you may use your own external speaker. Speaker/Buzzer (CN24) Speaker On Board Buzzer CN24 SBC-776 Chapter 2... -
Page 48: Fan Power Connector (Cn25, Cn26, Cn27)
Plug in the fan cable to the 3-pin fan connector onboard. The fan connector is marked CN26. CPU fan power connector (CN26) Signal +12V Fan speed sensor System fan 1 connector (CN 25) Signal +12V Fan speed sensor System fan 2 connector (CN27) Signal +12V Fan speed sensor BC-599/596 SBC-776 Manual... -
Page 49: Lcd Backlight Power Connector (Cn28)
LCD Backlight Power Connector (CN 28) LCD Backlight Power Connector (CN 28) Signal BLKVCC TFT LCD panel connector (CN 29) LCD panel connector (CN 29) Signal Signal BLKVCC BLKVCC LDCVCC LCDVCC ENA VEE SHF CLK VSYNC HSYNC FPBLEN SBC-776 Chapter 2... -
Page 50: Ps/2 Keyboard Header (Cn31)
Signal Signal KB CLOCK KB DATA PS/2 Mouse Header (CN 32) Onboard there is a 4-pin header for keyboard connection, the pin definition is provided below. PS/2 Mouse Header (CN 32) Signal Signal MS CLOCK MS DATA BC-599/596 SBC-776 Manual... -
Page 51: Chapter 3: Award Bios Setup
Award BIOS Setup This chapter describes how to configure the BIOS for the system. SBC-776 User Manual... -
Page 52: Starting Setup
Starting setup The Award BIOS is immediately activated when you first turn on the computer. The BIOS reads system configuration information in CMOS RAM and begins the process of checking out the system and configuring it through the power-on self test (POST). When these preliminaries are finished, the BIOS seeks an operating system on one of the data storage devices (hard drive, floppy drive, etc.). -
Page 53: Setup Keys
CMOS, only for Option Page Setup Menu Load the default CMOS RAM value from BIOS default table, only for Option Page Setup Menu Load the default Reserved Reserved Save all the CMOS changes, only for Main Menu SBC-776 User Manual... -
Page 54: Getting Help
Getting help Press F1 to pop up a small help window that describes the appro- priate keys to use and the possible selections for the highlighted item. To exit the Help Window press Esc or the F1 key again. In Case of Problems If, after making and saving system changes with Setup, you discover that your computer no longer is able to boot, the Award BIOS supports an override to the CMOS settings that resets your... -
Page 55: Main Setup Menu
Use this menu to specify your settings for integrated peripherals. (Primary slave, secondary slave, keyboard, mouse etc.) Power Management Setup Use this menu to specify your settings for power management. (HDD power down, power on by ring, KB wake up, etc.) SBC-776 User Manual... -
Page 56: Exit Without Saving
PnP/PCI Configuration This entry appears is your system supports PnP/PCI. PC Health Status This menu allows you to set the shutdown temperature for your system. Frequency/Voltage Control Use this menu to specify your settings for frequency/ voltage control. Load Fail-Safe Defaults Use this menu to load the BIOS default values for the minimal/ stable performance for your system to operate. -
Page 57: Hard Disks
The BIOS supports up to four IDE drives. This section does not show information about other IDE devices, such as a CD-ROM drive, or about other hard drive types, such as SCSI drives. NOTE: We recommend that you select type AUTO for all drives. SBC-776 User Manual... - Page 58 The BIOS can automatically detect the specifications and optimal operating mode of almost all IDE hard drives. When you select type AUTO for a hard drive, the BIOS detects its specifications If you do not want to select drive type AUTO, other methods of selecting the drive type are available: 1.Match the specifications of your installed IDE hard drive(s) with the preprogrammed values for drive types 1 through 45.
- Page 59 For EGA, VGA, SEGA, SVGA, or PGA monitor adapters. CGA 40 Color Graphics Adapter, power up in 40 column mode CGA 80 Color Graphics Adapter, power up in 80 column mode MONO Monochromoe adapter, includes high resolution monochrome adapters SBC-776 User Manual...
- Page 60 Halt On During the power-on-self-test (POST), the computer stops if the BIOS detects a hardware error. You can tell the BIOS to ignore certain errors during POST and continue the boot-up process. These are the selections: No errors : POST does not stop for any errors. All errors If : the BIOS detects any nonfatal error, POST stops and prompts you to take corrective action.
-
Page 61: Extended Memory
Between 640 KB and 1 MB; often called High memory. DOS may load, terminate-and-stay-resident (TSR) programs, such as device drivers, in this area, to free as much conventional memory as possible for applications. Lines in your CONFIG.SYS file that start with LOADHIGH, load programs into high memory. SBC-776 User Manual... - Page 62 Advanced BIOS Features The displayed configuration is based on the manufacturer's SETUP DEFAULTS settings. Virus Warning When enabled, you receive a warning message if a program (specifically, a virus) attempts to write to the boot sector or the partition table of the hard disk drive. You should then run an anti- virus program.
-
Page 63: Quick Power On Self Test
POST than lose data during your work. First/Second/Third/Fourth Boot Device The BIOS attempts to load the operating system from the devices in the sequence selected in these items. The choices: Floppy, LS/ZIP, HDD, SCSI, CDROM, Disable. SBC-776 User Manual... -
Page 64: Swap Floppy Drive
Swap Floppy Drive This field is effective only in systems with two floppy drives. Selecting enabled assigns physical drive B to logical drive A, and physical drive A to logical drive B. Boot Up Floppy Seek When Enabled, the BIOS tests (seeks) floppy drives to determine whether they have 40 or 80 tracks. -
Page 65: Security Option
System boots, or only when you enter Setup. OS Select For DRAM>64MB- Select the operating system that is running with greater than 64MB or RAM on the system. The choice: Non-OS2, OS2 SBC-776 User Manual... - Page 66 HDD S.M.A.R.T Capability Hard disk drives have built in problem detection capability (Self-Monitoring Analysis and Reporting Technology). If a foreseen problem is about to take place, the computer will give a you a warning signal. The choice: Enable, Disable Report No FDD For WIN 95- Report no FDD for Win 95 or not.
- Page 67 This field lets you insert a timing delay between the CAS and RAS strobe signals, used when DRAM is written to, read from, or refreshed. Fast gives faster performance; slow gives more stable performance. This field applies only when synchronous DRAM is installed in the system. SBC-776 User Manual...
-
Page 68: System Bios Cacheable
SDRAM RAS Precharge Time If an insufficient number of cycles is allowed for the RAS to accumulate its charge before DRAM refresh, the refresh may be incomplete and the DRAM may fail to retain date. Fast gives faster performance; slow gives more stable performance. -
Page 69: System Memory Frequency
64M. Display Cache Frequency Display cache frequency will allow for the level the of the share memory provided by the Intel 815E chipset to be adjusted. The settings are 100MHz and 133 MHz. System Memory Frequency Select the onboard display cache frequency. The settings are auto, 100MHz and 133MHz. -
Page 70: Integrated Peripherals
Integrated Peripherals On-Chip Primary PCI IDE The system chipset contains a PCI IDE interface with support for two IDE channels. Select Enabled to activate the primary and/or secondary IDE interface. Select Disabled to deactivate this interface, if you install a primary and/or secondary add-in IDE interface. -
Page 71: Usb Controller
I/O cycles to the ISA bus. This delay takes place because the PCI bus is much faster than the ISA bus. This field lets you add recovery time (in bus clock cycles) for 8-bit I/O. The choice: 0-7 SYSCLK SBC-776 User Manual... -
Page 72: Ide Hdd Block Mode
16-bit I/O Recovery Time The I/O recovery mechanism adds bus clock cycles between PCI- originated I/O cycles to the ISA bus. This delay takes place because the PCI bus is much faster than the ISA bus. This field lets you add recovery time (in bus clock cycles) for 16-bit I/O. The choice: 1 SYSCLK, 2SYSCLK, 3SYSCLK, 4 SYSCLK IDE HDD Block Mode Block mode is also called block transfer, multiple commands, or... -
Page 73: Onboard Fdc Controller
Half-duplex mode permits transmission in one direction only at a time. If no infrared port is present in the system, select disabled. Use IR Pins Consult your IR peripheral documentation to select the correct setting of the TxD and RxD signals. SBC-776 User Manual... -
Page 74: Onboard Parallel Port
Onboard Serial Ports (1, 2) Normally, the main board’s I/O chips will occupy a certain portion of memory space. For each I/O device the computer provides an I/O address. The more devices attached the more address needed to organize the memory storage areas. If all the I/O devices were run through the same address, your devices would come to a near halt. -
Page 75: Watch Dog Timer
( select the time period in a separate field ) The choice: Disabled, 20 sec, 30 sec, 40 sec, 50 sec, 1 min, 2 min, 4 min. SBC-776 User Manual... -
Page 76: Power Management Setup
Power Management Setup ACPI Function This item allows you to enable/disable the Advanced Configuration and Power Management (ACPI). The Choices: Enable/Disable ACPI Suspend Type This item will set which ACPI suspend type will be used. S1 (POS) The S1 sleeping state is low wake-up latency sleeping state. -
Page 77: Power Management
I a i t i l a SBC-776 User Manual... -
Page 78: Video Off In Suspend
Video Off In Suspend After the selected period of system inactivity, the chipset enters a hardware suspend mode, stopping the CPU clock and possibly causing other system devices to enter power management modes. In this case the video hardware can be selected to shut off after a period of system inactivity. -
Page 79: Power On After Power Fail
RAM. The choices: Enable, disable Date Alarm You can choose which month the system will boot up. Set to 0 to boot everyday. Time Alarm You can choose what hour, minute and second the system will boot SBC-776 User Manual... - Page 80 <Reload Global Timer Events> PM events are I/O events whose occurrence can prevent the system from entering a power saving mode or can awaken the system from such a mode. In effect, the system remains alert for anything which occurs to a device which is configured as Enabled, even when the system is in a power down mode.
-
Page 81: Pnp Os Installed
Extended System Configuration Data (ESCD) when you exit Setup if you have installed a new add-on and the system reconfiguration has caused such a serious conflict that the operating system can not boot. The choices: Enabled, Disabled SBC-776 User Manual... -
Page 82: Resources Controlled By
Resources Controlled By The Award Plug and Play BIOS has the capacity to automatically configure all of the boot and Plug and Play compatible devices. However, this capability means absolutely nothing unless you are using a Plug and Play operating system such as Windows ® 95. If you set this field to “manual”... -
Page 83: Pc Health Status
Your system can be configured to shutdown once reaching a certain temperature. To protect your system from overheating or damage, select a certain temperature level in the PC Health Status menu. Options: Disabled, 75°C/167°F, 70°C/158°F, 65°C/149°F, 60°C/140°F SBC-776 User Manual... -
Page 84: Frequency/Voltage Control
100 MHz or 99 MHz to 66 MHz depending on the CPU host clock. CPU Clock Ratio This item allows you to select the CPU ratio. When using an Intel CPU this item will be hidden. Chapter 3 Award BIOS Setup... -
Page 85: Load Fail-Safe Defaults
When you press <Enter> on this item you get a confirmation dialog box with a message similar to: Load Fail-Safe Default (Y/N)? Pressing “Y” loads the BIOS default values for the most stable, minimal performance system operations. SBC-776 User Manual... -
Page 86: Load Optimized Defaults
Load Optimized Default Load Optimized Default When you press <Enter> on this item you get a confirmation dialog box with a message similar to: Load Optimized Defaults (Y/N)? Pressing “Y” loads the default values that are factory settings for optimal performance system operations Chapter 3 Award BIOS Setup... -
Page 87: Set Supervisor Password
System Enter a password each time the system boots and when ever you enter Setup. Setup Enter a password when ever you enter Setup. NOTE: To clear the password, simply press Enter when asked to enter a password. Then the password function is disabled. SBC-776 User Manual... -
Page 88: Set User Password
Set User Password When you select this function, a message appears at the center of the screen: ENTER PASSWORD: Type the password, up to eight characters, and press Enter. Typing a password clears any previously entered password from CMOS memory. Now the message changes: CONFIRM PASSWORD: Again, type the password and press Enter. - Page 89 The next time you boot your computer, the BIOS configures your system according to the Setup selections stored in CMOS. After saving the values the system is restarted again. SBC-776 User Manual...
-
Page 90: Quit Without Saving
Quit without Saving Exit Without Saving Pressing <Enter> on this item asks for confirmation: Quit Without Saving (Y/N)? This allows you to exit Setup without storing in CMOS any change. The previous selections remain in effect. This exits the Setup utility and restarts your computer. -
Page 91: Drivers Installation
DRIVERS INSTALLATION This SBC-776 is equipped with an audio, VGA and Dual LAN interface. This chapter provides instructions for installing the software drivers on these pheripherals. SBC-776 User Manual... -
Page 92: Intel 82562Et Lan Driver
5. Intel 815E VGA Driver 5.1 For WIN95/98/Me 5.2 For WIN2000 5.3 For WIN NT4.0 6. Ultra ATA Storage Driver 6.1 For WIN98/2000/NT4.0 PS For WIN95: Intel did not release an Ultra ATA storage driver for WIN95. Notice: Attention Chapter 4 Drivers... - Page 93 Notice: Attention 7. Advance Logic ALC200 Sound Driver 7.1 For WIN95 7.2 For WIN98 7.3 For WIN Me 7.4 For WIN2000 7.5 For Win NT 4.0 Notice: Attention SBC-776 User Manual...
- Page 94 Software Installation Utility 1.1 For WIN95/98/2000/Me ~~>Install the CDROM Driver into the CD disk drive. ~~>Find the Software Installation Utility Folder ~~>Find the WIN95/95/2000/Me folder ~~>Find the infinst_enu folder ~~>Find the disk 1 folder ~~>Find the setup icon and then double click ~~>Click on Next ~~>Click on Yes ~~>Click on Next, install the utility...
-
Page 95: Intel 82562Et Lan Driver
~~>Select your OS folder (WIN98/Me or WIN2000 folder) ~~>Click on Next ~~>Appear net82557.inf, click on Open ~~>Click on OK ~~>Find Intel PRO/100 VE Network Connection ~~>Click on Next ~~>Click on Next, install the driver ~~>Click on Finish ~~>Click on Close to finish the 82562ET driver... - Page 96 ~~>Click on Next ~~>Click on Select from List..~~>Click on Have Disk ~~>Click on OK ~~>Click on OK ~~>Appear Intel Pro Adapter ~~>Click on OK ~~>Click on Next ~~>Select TCP/IP Protocol, NWlink IPX/SPX Compatible Transport, NetBEUI Protocol (PS: This depends on your system) ~~>Click on Next...
- Page 97 ~~>Type the Workgroup name, click on Next ~~>Click on Yes ~~>Appear Do you want to restart your computer now? Click on Yes. SBC-776 User Manual...
-
Page 98: Advansys 38C0800 Scsi Driver
Advansys 38C0800 SCSI Driver 3.1 & 3.2 Installation Procedures are identical. ~~>Place CDROM into CD disk drive ~~>Click on Start button ~~>Click on Settings button ~~>Click on Control Panel button ~~>Click on Systems button ~~>Click on Device Manager button ~~>Click on SCSI Controller ~~>Click on Reinstall Driver ~~>Click on Next ~~>Select Display a list of know drivers for this.. - Page 99 ~~>Find the WIN NT 4.0 folder, under the name of nt4adv.inf ~~>Click on Open ~~>Click on OK ~~>Click on Next ~~>Select WIN NT 4.0 Advansys Ultra 2 Wide SCSI Adapter ~~>Appear Do you want to restart your computer now? Click on yes. SBC-776 User Manual...
-
Page 100: Intel 82559Er Lan Driver
Intel 82559ER LAN Driver 4.1 Installation Direction for Intel 82559ER LAN Driver ~~>Place CDROM into CD disk drive ~~>Click on Start button ~~>Click Settings button ~~>Click on Control Panel button ~~>Click on System button ~~>Click on Device Manager button ~~>Click on PCI Ethernet Controller ~~>Click on Reinstall Driver... - Page 101 ~~>Click on Adapters ~~>Click on ADD ~~>Click on Have Disk ~~>Click on OK ~~>Appear Intel 82559ER fast ethernet adapter ~~>Click on OK to install driver ~~>Click on Close ~~>Setup your TCP/IP Properties ~~>Appear Do you want to restart your computer now? Click on Yes.
-
Page 102: Vga Driver
Intel 815E VGA Driver 5.1, 5.2 & 5.3 Installation Procedures ~~>Place the CDROM into the CD disk drive ~~>Find the VGA folder ~~>Select your OS folder (WIN95/98/2000/NT) ~~>Select Graphic folder ~~>Select Setup icon, double click ~~>Click on Next ~~>Click on Yes, install VGA driver ~~>Click on finish, restart my computer now... -
Page 103: Ultra Ata Storage Driver
Intel Ultra ATA Storage Driver 6.1 Installation procedures ~~>Place the CDROM into the CD disk drive ~~>Find the Ultra ATA driver folder ~~>Find the intel ATA603_enu icon, double click select graphic folder ~~>Click on Next ~~>Click on Yes ~~>Click on Next ~~>Click on Next... - Page 104 Advance Logic ALC200 Sound Driver 7.1-7.5 Installation procedures ~~>Place the CDROM into the CD disk drive ~~>Click on Advance ALC200 folder ~~>Select your OS folder (WIN95/98/2000/Me/NT) ~~>Double click on Setup icon ~~>You will see an optional language window, select English ~~>Click on Next ~~>Click on go ~~>Click on Yes...
