Video Support

The Intel® Server Board S300 0PT includes an integrated standalone ATI* ES1000 graphics
engine that supports standard VGA drivers with analog display capabilities. The graphics
subsystem has 16 MB of dedicated memory to support the onboard video controller. The
baseboard provides a standard 15 -pin VGA connector at the rear of the system, in the I/O
opening area.
3.5.1.1 Video Modes
2D Mode Refresh Rate (Hz)
640x480 60, 72, 75, 90, 100
800x600 60, 70, 75, 90, 100
1024x768 60, 72, 75, 90, 100
1280x1024 43, 60
1280x1024 70, 72
3D Mode Refresh Rate (Hz)
640x480 60,72,75,90,100
800x600 60,70,75,90,100
1024x768 60,72,75,90,100
1280x1024 43,60,70,72
3D Mode Refresh Rate (Hz)
640x480 60,72,75,90,100
800x600 60,70,75,90,100
1024x768 60,72,75,90,100
1280x1024 43,60,70,72
3.5.2

Network Interface Controller (NIC)

The Intel® Server Board S3000PT supports two 10/100/1000 Base-T network interfaces.
NIC1 is an Intel® 82573E Gigabit Ethernet Controller resourced with a x1 PCI Express*
interface from the Intel® ICH7R (PCI Segment C).
NIC2 is an Intel® 82573V Gigabit Ethernet Controller resourced with a x1 PCI Express*
interface from the Intel® ICH7R (PCI Segment B).
Both the Intel® 82573E and Intel® 82573V Gigabit Ethernet Controllers are single,
compact components with an integrated gigabit Ethernet Media Access Control (MAC)
and physical layer (PHY) function. The Intel® 82573E and Intel® 82573V Gigabit
Ethernet Controller allow for a gigabit Ethernet implementation in a very small area that
is footprint compatible with current generation 10/100 Mbps Fast Ethernet designs.
Intel® 82573E/V integrates fourth and fifth generation (respectively) giga bit MAC design
with fully integrated physical layer circuitry to provide a standard IEEE 802.3 Ethernet
Revision 1.3

Table 11. Video Modes

2D Video Mode Support
8 bpp 16 bpp
Supported Supported
Supported Supported
Supported Supported
Supported Supported
Supported
3D Video Mode Support with Z Buffer Enabled
8 bpp 16 bpp
Supported Supported
Supported Supported
Supported Supported
Supported Supported
3D Video Mode Support with Z Buffer Disabled
8 bpp 16 bpp
Supported Supported
Supported Supported
Supported Supported
Supported Supported
Functional Architecture
24 bpp
Supported
Supported
Supported
Supported
– Supported
24 bpp
Supported
Supported
Supported
–
24 bpp
Supported
Supported
Supported
Supported
32 bpp
Supported
Supported
Supported
Supported
Supported
32 bpp
Supported
Supported
Supported
–
32 bpp
Supported
Supported
Supported
–
