Table 1. Server Board Layout Reference - Intel S3000PT - Server Board Motherboard Specification

Intel® Server Board S3000PT TPS
Ref
A Post LEDs
B PCI-E x8 riser slot
C BIOS Flash(SPI)
D Intel® 82802 ICH7R
E Clock generator
F SMSC* SCH5027 or SMSC* SCH5017
Super I/O (SIO)
®
G Intel 3000 Memory Controller Hub
(MCH)
H 775-Land (LGA) CPU Socket
I System Fan 1 (8-pin)
J System Fan 2 (8-pin)
K System Fan 3 (8-pin)
L 2 x 7 Front Panel header
M 2 x 9 Power connector
N Auxiliary Fan (4-pin)
O Memory Slot DIMM 2B
P Memory Slot DIMM 1B
Q Memory Slot DIMM 2A
R Memory Slot DIMM 1A
Revision 1.3

Table 1. Server Board Layout Reference

Description Ref Description
S Battery
T USB 3 and 4 header
U SATA port 2
V SATA port 1
W Serial B header
X Video Memory
Y Intel® 82573E LAN Controller
Z Intel® AMT firmware (NIC1) update jumper
AA Clear CMOS jumper
BB NIC1 SPI Flash
CC Intel® 82573V LAN Controller
DD SMBus Connector
EE NIC1 RJ-45 and USB 1 and 2 connector
FF NIC2 RJ-45 connector
GG NIC2 SPI EEPROM
HH Serial A connector
JJ VGA connector
KK ATI* ES1000 video controller
Server Board Overview
5
