Functional Architecture
interface for 1000BASE-T, 100BASE-TX, and 10BASE-T applications (802.3, 802.3u,
and 802.3ab). The controller is capable of transmitting and receiving da ta at rates of
1000 Mbps, 100 Mbps, or 10 Mbps.
3.5.2.1 NIC Connector and Status LEDs
The NICs drive two LEDs located on each network interface connector.
LED Color
Left Green
N/A
Right Green
Yellow
LED Color
Right Green
N/A
Left
Green
Yellow
3.5.3

Super I/O Chip

The SMsC* SCH5027 or SCH5017 SIO devices contain all of the necessary circuitry to control
serial/parallel ports, floppy disk, PS/2-compatible keyboard, mouse and hardware monitor
controller. The baseboard implements the following features:
GPIOs
One full functional serial port
One Tx/Rx only serial port for debug only
Local hardware monitoring
Wake up control
System health support
3.5.3.1 Serial Ports
The board provides a serial port implemented as an external 9 -pin serial port; an internal 3-pin
Tx/Rx only serial port is also provided. The following sections provide details on the use of the
serial port.
22
Table 12. Intel® 82573E Interface Connector (NIC1)
LED State
Off
On
Blinking
Off
On
On
Table 13. Intel® 82573V Interface Connector (NIC2)
LED State
Off
On
Blinking
Off
On
On
Intel® Server Board S3000PT TPS
Condition
LAN link is not established.
LAN link is established.
LAN activity is occurring.
10 Mbit/sec data rate is selected.
100 Mbit/sec data rate is selected.
1000 Mbit/sec data rate is selected.
Condition
LAN link is not established.
LAN link is established.
LAN activity is occurring.
10 Mbit/sec data rate is selected.
100 Mbit/sec data rate is selected.
1000 Mbit/sec data rate is selected.
Revision 1.3
