Connectors and Jumper Blocks
7.3
Front Panel Connector
A 14-pin header is provided to support a system front panel. The header contains reset, NM I,
power control buttons, and LED indicators . The following table details the pin -out of this header.
Power LED Anode
Power LED Cathode
HDD Activity LED Anode
HDD Activity LED
Cathode
Power Switch
Power Switch(GND)
Key (pin removed)
Note: NC (No Connect)
7.4
I/O Connectors
7.4.1
VGA Connector
The following table details the pin -out of the VGA connector.
RED
GREEN
BLUE
NC
GND
GND
GND
GND
Note: NC (No Connect)
Revision 1.3
Table 47. Front Panel 14-pin Header Pin-out (J4K3)
Signal Name
Pin
1
3
5
7
9
11
13
Table 48. VGA Connector Pin-out (J4A1)
Signal Name
Intel® Server Board S3000PT TPS
Signal Name
NIC1 Activity LED Anode
NIC1 Activity LED
Cathode
NIC2 Activity LED Anode
NIC2 Activity LED
Cathode
Reset Switch
Reset Switch (GND)
NC
Pin
Signal Name
1
Fused VCC (+5V)
2
GND
3
NC
4
DDCDAT
5
HSY
6
VSY
7
DDCCLK
8
Pin
2
4
6
8
10
12
14
Pin
9
10
11
12
13
14
15
65
