Table 6. Characteristics of Dual/Single Channel Configuration with or without Dynamic Mode

Throughput Level
Highest Dual channel with dynamic paging mode
Dual channel without dynamic paging mode
Single channel with dynamic paging mode
Lowest Single channel without dynamic paging
mode
3.3.1

Memory DIMM Support

The board supports un-buffered (not registered) DDR2 533/667 ECC DIMMs operating at
533/667MT/s. Only DIMMs tested and qualified by Intel o r a designated memory test vendor are
supported on this board. A list of qualified DIMMs is available at
http://support.intel.com/support/motherboards/server/
Note: All DIMMs are supported by design, but only fully qualified DIMMs will be supported on
the board.
The minimum supported DIMM size is 256 MB. Therefore, the minimum main memory
configuration is 1 x 256 MB or 256 MB. The largest size DIMM supported is 2 GB and as such,
the maximum main memory configuration is 8 GB implemented by 4 x 2-GB DIMMs.
Only un-buffered DDR2 533/667 compliant, ECC x8 or x16 memory DIMMs are
supported.
ECC single-bit errors (SBE) will be corrected; multiple -bit error (MBE) will only be
detected.
Intel® Server Board S3000PT supports Intel® x4 Single Device Data Correction with x4
DIMMs.
The maximum memory capacity is 8 GB via four 2 -GB DIMM modules.
The minimum memory capacity is 256 MB via a single 256-MB DIMM module.
3.4

I/O Sub-System

3.4.1

PCI Subsystem

There are three independent PCI bus segments directed from the Intel® ICH7R controller on
the Intel® Server Board S3000PT. PCI Segment A is a legacy PCI bus while PCI Segments B
and C are PCI Express*.
Revision 1.3
Configuration
Functional Architecture
Characteristics
All DIMMs matched
DIMMs matched from Channel A to Channel B
DIMMs not matched within channels
Single DIMM or DIMMs matched within a
channel
DIMMs not matched
.
15
