Intel® Server Board S3000PT TPS

Table 55. Optional USB Connection Header Pin -out (J1C1)

Signal Name
NC
GND
USB_FRONT1_INDUCTOR_DP
USB_FRONT1_INDUCTOR_DN
USB_FNT_PWR (Fused VCC, +5V /w over current
monitor of port 1)
7.5

Fan Headers

There are three general-purpose (system) fan headers (J3K1,J4K2,J4K1). These fan headers
have the same pin-out and are detailed in the following table .
Pin Signal Name
1 Ground
2 Fan Power
3 Fan Tach1
4 PWM1
5 Ground
6 Fan Power
7 Fan Tach2
8 PWM1
68

Table 56. 8-pin Fan Headers Pin-out (J3K1,J4K2,J4K1)

Type
Power GROUND is the power supply ground
Power Fan Power +12VDC
Sense FAN_TACH signal is connected to the SMsC* SCH5027 or SCH5017 to
monitor the fan speed.
Control Pulse Width Modulation – Fan speed Control signal
Power GROUND is the power supply ground
Power Fan Power +12VDC
Sense FAN_TACH signal is connected to the SMsC* SCH5027 or SCH5017 to
monitor the fan speed. It use a different TACH input other than TACH1.
Control Pulse Width Modulation – Fan speed Control signal . It used the same
PWM signal as PWM1
Connectors and Jumper Blocks
Pin Signal Name
1 Key (pin removed)
3 GND
5 USB_FRONT2_INDUCTOR_DP
7 USB_FRONT2_INDUCTOR_DN
9 USB_FNT_PWR (Fused VCC, +5V /w over current
monitor of port 1)
Description
Pin
2
4
6
8
10
Revision 1.3
