Intel
Server Board S5000PSL,
®
Intel
Server Board S5000XSL,
®
Intel
Workstation board S5000XVN,
®
Intel
Server Chassis SC5400, and
®
Intel
Entry Server Chassis SC5299-E
Spares Parts List and Configuration Guide
A reference guide to help customers order the necessary components to configure the Intel
Server Board S5000PSL and Intel
chassis.
®
Workstation Board S5000XVN with the appropriate Intel
®
Rev 2.0
April, 2010
~ Subject to Change ~
I
Advertisement
Table of Contents
Related Manuals for Intel S5000PSLSAS
Summary of Contents for Intel S5000PSLSAS
- Page 1 Intel Entry Server Chassis SC5299-E Spares Parts List and Configuration Guide ® A reference guide to help customers order the necessary components to configure the Intel ® Server Board S5000PSL and Intel Workstation Board S5000XVN with the appropriate Intel chassis.
- Page 2 Intel products including liability or warranties relating to fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property right. Intel products are not intended for use in medical, life saving, or life sustaining applications. Intel may make changes to specifications and product descriptions at any time, without notice.
-
Page 3: Table Of Contents
Production SKU Details and Contents ............4 ® ® 4 Production Configuration and Ordering Steps (Intel Server Board S5000PSL / Intel Server Board S5000XSL) Production Configuration and Ordering Steps (S5000XVN) ..... 8 Production Configuration ................12 ... -
Page 4: Production Sku Details And Contents
® S5000XSL) ® ® This section highlights the ordering steps and configurations for the Intel Server Board S5000PSL and Intel Server Board S5000XSL server board families. More detailed information is in the following sections. Step 1 – Select a Server Board... - Page 5 Step 5: Choose an optional Intel® SAS/SATA RAID Controller = Supported The Intel Server Board S5000PSLROMB comes with Intel Integrated Server RAID. This ROMB Card consumes a PCI Express slot and provides 8 SAS ports. With the optional Activation Key (AXXRAK18E), hardware 0, 1, 5, 10, 50 RAID is activated.
- Page 6 Step 7b: Choose Intel Server Chassis SC5299 family key accessories APP3HSDBKIT APP3RACKIT - Hot-swap drive bay fan and adaptor kit - Rack conversion kit for SC5299 family - Required for when adding optional hot-swap drive bays in SC5299DP and SC5299BRP chassis...
- Page 7 Processor Number Product Code 5160 (3.00 GHz, 1333 MHz FSB) BX805565160P 5150 (2.66 GHz, 1333 MHz FSB) BX805566150P 5148 (2.33 GHz, 1333 MHz FSB, Low Voltage) BX805565148P 5140 (2.33 GHz, 1333 MHz FSB) BX805565140P 5138 (2.13 GHz, 1066 MHz FSB, Low Voltage) BX805565138P 5130 (2.00 GHz, 1333 MHz FSB) BX805565130P...
-
Page 8: Production Configuration And Ordering Steps (S5000Xvn)
AXXDVDCDR (Step 7) in the SC5400 family of chassis Production Configuration and Ordering Steps (S5000XVN) ® This section highlights the ordering steps and configurations for the Intel S5000XVN Workstation boards. More detailed information is in the following sections. Step 1 – Select a Workstation Board... - Page 9 AXXUSBFLOPPY ARIGDLTRAIL - DLT Accessory Kit (10 pack of rails) - Slim-line floppy for use with AXXCDUSBFDBRK Step 6b: Choose Intel Server Chassis SC5299 family key accessories APP3HSDBKIT APP3RACKIT - Hot-swap drive bay fan and adaptor kit - Rack conversion kit for SC5299 family...
- Page 10 Step 7b: Choose Intel Server Chassis SC5299 family key accessories APP3HSDBKIT APP3RACKIT - Hot-swap drive bay fan and adaptor kit - Rack conversion kit for SC5299 family - Required for when adding optional hot-swap drive bays in SC5299DP and SC5299BRP chassis...
- Page 11 5063 (3.20 GHz, 1066 MHz FSB) BX805555063A 5060 (3.20 GHz, 1066 MHz FSB) BX805555060A 5050 (3.00 GHz, 667 MHz FSB) BX805555050A 5030 (2.67 GHz, 667 MHz FSB) BX805555030A Continue with Steps 8 and 9 in section above to order processors and non-Intel accessories...
-
Page 12: Production Configuration
Production Configuration ® ® This section contains information needed to order and configure the Intel Server Chassis SC5400 and Intel Server ® Chassis SC5299 KDKs with Intel Server Board families S5000PSL, S5000XSL, and S5000XVN. Production-boxed Intel Server Boards contain the following: ... - Page 13 AC power cord is included only in SC5400BRPNA ® ® ® The Intel Server Chassis SC5400 is designed to work with the boxed Intel Xeon processor 5000 sequence using a 2U passive heat sink. The production SC5400 Base KDK includes: ...
- Page 14 Chassis intrusion switch assembly ® ® The chassis is designed to work with the boxed Intel Xeon processor 5000 sequence using an active heat sink. The production SC5299DP SKU includes: Non-redundant 550-W PFC power supply One non-redundant cooling fan ...
-
Page 15: Production Board Skus
S5000PSL, S5000XSL, and S5000XVN board families. APP4650WPSU: Additional 650-W power supply module- required for full redundancy for SC5299BRP only. ® APP3HSDBKIT: Cooling and mounting kit required for 6-drive hot-swap backplanes installed in the Intel Entry Server Chassis SC5299 chassis family. -
Page 16: Production Chassis
(Refresh SKU) BB5000PSLROMBR 901719 00735858196147 OEM 5-pack of server board with S5000P ® chipset, six SATA ports and Intel Integrated RAID via 8-port SAS ROMB card (RAID activation requires optional key, Product code: AXXRAK18E and a 256MB-1GB DDR2-400 ECC DIMM purchased separately.) (Refresh SKU) - Page 17 SC5400 LX Chassis with two 830-W redundant PSU, four hot-swap redundant fans, one PSU fan per module, includes six drive HSBP, upgradeable to ten hot-swap ® SAS or SATA drives. Supports Intel Server Board ® S5000PSL and Intel Server Board S5000XSL board families.
-
Page 18: Production Spares And Accessories
SRCSAS144E RAID card. ® ® AXXRMM2 888501 0073585819240 Intel Remote Management Module 2 for Intel ® SC5000PSL server board family. Not supported in Intel S5000XVN workstation board family. FXX830WPSU 877872 00735858180269 SC5400LX and SC5400BRP 830-W optional, redundant power supply module. - Page 19 (4) of fixed hard drive bay rails, and (1) IDE cable. ® APP3HSDBKIT 882456 00735858177450 Hot-swap adapter bracket for use with all Intel Entry Server Chassis SC5299-E and SC5295 chassis. This accessory is required when using the 6 drive SATA/SAS hot-swap drive bays.
- Page 20 00735858180214 Intel SC5400BRP/SC5400LX Power Distribution board, power supply cage, power supply filler panel. You can ® use this accessory to upgrade the Intel Server Chassis ® SC5400BASE to the Intel Server Chassis SC5400BRP with the purchase of the power supply module...
- Page 21 ® FRIG2FIXFANS 877885 00735858180245 Intel Server Chassis SC5400 fixed fan spare kit. Includes one 92 mm and one 120 mm standalone fans ® (fixed fans for Intel Server Chassis SC5400BASE and ® Intel Server Chassis SC5400BRP). FXXLPSASCBL 877903 00735858180252 Spare SAS “Octopus” cable for use with SAS ROMB card included with S5000PSLROMB and BB5000PSLROMB boards.
- Page 22 878135 00735858180085 Pack of ten spare IPMB cables. ® FXXSESCBL 877945 00735858180092 Pack of ten spare SES cables used for the Intel Server Chassis S5000PSL ROMB solution. FXXSGPIOCBL 877944 00735858180108 Spare SGPIO cable used for ESB2 RAID to backplane communications.
-
Page 23: Production Raid Products
® FPWRCABLENA 879287 00735858180740 North America Power cable for Intel SC5400 family of chassis. ® Note: This power cable is NOT the same cable as Intel ® SC5300 or Intel SC5295/5299 chassis families. ® PWRCABLEUS 816324 00735858162883 Spare North American power cable for Intel SC5300, ®... - Page 24 72 hours retention. RoHS Compliant. ® AXXRSBBU3 883471 00735858181853 Intelligent Battery Backup module for use with the Intel RAID controller SRCSAS144E, S5000PSLROMB/S5000PSLROMBR SKUs, and SRCSASJV. Provides up to 72 hours of cache memory retention (depending on memory capacity and the number of memory components on the DIMM to support the capacity).
-
Page 25: Vmware Vsphere* Virtualization Software Configuration Guide For Vsphere* Skus
VMware vSphere* software is now available when ordering an Intel® Server Board or Intel® Server System. Customers can only order these SKUs at the time they are ordering an Intel® Server Board or Intel® Server System. These SKUs cannot be ordered individually. - Page 26 Enterprise Plus This license activation code gives the user VMware vSphere* 4 Enterprise Plus for 1 Processor (Max 12 cores per CPU), with 1 year VMware Gold Support and Subscription. VMware vCenter* Server Standard for vSphere* This license activation code gives the user VMware vCenter* Server 4 Standard for vSphere* (Includes Orchestrator and Linked Mode), with 1 year VMware Gold Support and Subscription.
