Note:
If you will be configuring the Ethernet card using the card's home
page, you must assign an IP address manually here.
The default IP address is 11.22.33.44. If you configure the
Ethernet card using the card's home page, you must change the
default IP address.
If a server or router acts as a gateway, type the gateway address. If
there is no gateway, type the IP address of your computer.
7. Click OK to save the new settings. The update is complete when
the message "Configuration is successfully done" appears.
c
Caution:
After clicking OK, you must wait approximately three seconds
before turning off the printer while the new settings are sent to
the Ethernet card.

Getting information about other network segments

To get information for interface cards on the other segments, use the
Subnet Settings in the EPSON Net!2 for Windows Option menu.
1. Type the subnet address you want to search from 0 to 255 at the
box.
Click Add to add the subnet in the Subnet List box. The interface
2.
cards in the subnet address you added are searched and are listed
on the EPSON Net!2 dialog box.
3. When you want to delete the subnet address from the list, click
the subnet address in the Subnet List box, and then click Delete.
4. Click OK to exit.
Setting the IP Address 3-13
