Chapter 2 Basic Operations
Removing the Magazines
Figure 29 Removing
the Level 1 Left
Magazine
42
While holding the release latch, pull the level 1 left magazine
g
forward and out of the library (see
Reinsert the level 2 left magazine into the library and close the
h
bottom left magazine access door.
3 To remove any other magazine:
Press the button next to the desired magazine access door.
a
If you are opening the bottom left magazine access door,
Note:
open the top left magazine access door first.
The magazine access door opens.
Grasp the handle at the front of the desired magazine and slide it
b
forward and out of the library.
Tandberg Data M-Series User's Guide
figure 29).
