2 Press the button corresponding to the magazine you want to release:
• To release both magazines, press
• To release the left magazine, press
• To release the right magazine, press
The GUI indicates that the magazine or magazines have been
released.
3 Press the button next to the desired magazine access door and open
the door.
4 Grasp the handle at the front of the magazine and pull it forward and
out of the library.
5 When you are finished adding or removing cartridges from the
magazine, replace it in the library and close the magazine door.
6 On the
Release Magazines
The library locks the magazine access doors and inventories the
magazines. When the inventory is complete, the GUI displays the
main screen.
Removing a Magazine when the M1500 Library is Powered Down
To remove a magazine when the library is powered down:
1 Look through the viewing window and verify that all cartridges are
fully seated either in a magazine slot or in the robotic hand.
You can damage the library severely if you try to
Caution:
remove a magazine when one of the data cartridges is
not fully seated.
2 Press the button next to the magazine access door.
The magazine access door opens.
Tandberg Data M-Series User's Guide
Chapter 2 Basic Operations
Removing the Magazines
.
Both
.
Left
.
Right
screen, press
Re-Lock
.
