Figure 27 Removing
the Level 2 Left
Magazine
Figure 28 Release
Latch
Press the button next to the bottom left magazine access door and
d
open the door.
Remove the level 2 left magazine (see
e
Reach into the library underneath the level 1 left magazine and
f
pull down on the release latch (see
Release latch
Tandberg Data M-Series User's Guide
Chapter 2 Basic Operations
Removing the Magazines
figure 27).
figure 28).
41
