Figure 4 M2500 Internal Layout - Tandberg Data MSERIES USER User Manual

Figure 4 M2500
Internal Layout
Level 1 left
magazine*
Level 2 left
magazine*
Level 3 left
magazine*
Level 4 left
magazine*
*There is a fixed slot
behind each left
magazine.
tape drive 1
(Library shown with front bezel and doors removed)
Level 1
tape drive 1
Level 2
Level 3
tape drive 1
Tandberg Data M-Series User's Guide
Robotic Level 1
hand tape drive 2
Level 3
tape drive 2
Chapter 1 Overview
Library Features
Level 1 right
magazine
Level 2 right
magazine
Level 3 right
magazine
Level 4 right
magazine
Level 2
tape drive 2
9
