Appendix B Fault Symptom Code (FSC) Dictionary
FSC Name
2636 FSC_SERVO_SHUTTLE_
CALIBRATION_ERROR
2637 FSC_SERVO_SHUTTLE_
PICKER_CALIBRATION_
ERROR
2638 FSC_SERVO_GROSS_
POSITION_ERROR
2639 FSC_SERVO_SLOT_
CALIBRATION_ERROR
263A FSC_SERVO_DRIVE_FXD_
SLOT_CALIBRATION_
ERROR
263B FSC_SERVO_CLEANING_
TAPE_EXPIRED
263C FSC_SERVO_NOT_
CLEANING_TAPE
263D FSC_SERVO_SHUTTLE_
NOT_IN_POSITION
263E FSC_SERVO_
CARTRIDGE_NOT_
FULLY_HOME_IN_
SHUTTLE
263F FSC_SERVO_
CARTRIDGE_NOT_
FULLY_HOME_IN_DRIVE
128
Description
The shuttle's X axis
offset is too great
The shuttle is set too
far back on the Picker
axis
One of the axes has
suffered a gross
position error
The cartridge position
error detected on the Y
axis is too great
The cartridge position
error detected on the X
axis is too great
The cleaning tape in
use has expired
The auto-clean cycle
has loaded a non-
cleaning or invalid
tape
The shuttle has not
been detected opposite
the Picker during
calibration
The cartridge is not
fully in the shuttle,
manual intervention
required
The cartridge is not
fully in the drive,
manual intervention
and power cycle are
required
Tandberg Data M-Series User's Guide
FRU Name Confidence %
