Chapter 2 Basic Operations
Using the Mailbox
34
4 Pull the magazine forward until it stops.
5 Insert the cartridge you wish to import into the mailbox.
6 Reinsert the magazine into the library.
7 Close the magazine access door.
8 On the
Mailbox - OPEN
The library locks the magazine access door and the cartridge is
moved under control of the host software to the desired location.
Exporting a Cartridge in 1-Slot Mode
To export a cartridge in 1-slot mode:
1 Use the backup software to export cartridges to the first slot of the top
left magazine.
2 On the main screen, press
The GUI displays the
3 Press .
Open
The GUI displays the
4 Press the button next to the top left magazine access door and open
the door.
5 Pull the magazine forward until it stops.
6 Remove the exported cartridge from the magazine.
7 Reinsert the magazine into the library.
8 Close the magazine access door.
9 On the
Mailbox - OPEN
The library locks the magazine access door.
Tandberg Data M-Series User's Guide
screen, press
Re-Lock
.
Mailbox
screen (see figure
Mailbox
screen (see
Mailbox - OPEN
screen, press
Re-Lock
.
22).
figure 23).
.
