Switching Plane Connections from the TX Matrix Plus Router to the T1600 Routers

Switching Plane Description

LCC 0
T1600 Router
0
1
2
3
4
0
1
2
3
4
LCC 2
T1600 Router
Fiber-Optic Array Cable Connections Between TX Matrix Plus Routers and T1600 Routers
Copyright © 2010, Juniper Networks, Inc.
Chapter 3: Routing Matrix with a TX Matrix Plus Router System Architecture Overview
Switching Plane Description on page 63
Fiber-Optic Array Cable Connections Between TX Matrix Plus Routers and T1600
Routers on page 63
Fiber-optic array cables connect the TXP-F13 SIBs to the TXP-T1600 SIBs on the T1600
router.Figure 35 on page 63 shows the switching plane connections between the TX
Matrix Plus router and four T1600 routers.

Figure 35: Switching Plane Connections

Even
TX Matrix Plus
The cable connections provided in Table 22 on page 64 apply to routing matrix
configurations with up to four T1600 routers. For example, a four-router configuration
contains TXP-F13 SIBs in slots 1, 3, 4, 6, 7, 8, 9, 11, and 12. Slots 2, 5, 10, 13, 14, and 15 are
Odd
0
1
3
4
6
7
8
9
11
12
15
Router
LCC 1
T1600 Router
0
1
2
3
4
0
1
2
3
4
LCC 3
T1600 Router
