TX Matrix Plus TXP-CB Overview

If the TX Matrix Plus router contains a redundant host subsystem, one TXP-CB functions

as the master and the other as its backup. If the master fails or is removed, the backup

restarts and becomes the master.

The TX Matrix Plus router supports the TXP-CB.

TX Matrix Plus Host Subsystem Description on page 20

TX Matrix Plus TXP-CB Overview on page 21

TX Matrix Plus Routing Engine Description on page 25

TXP-CB Description on page 21

Routing Engine Ports on the TXP-CB on page 23

Each TXP-CB (see Figure 9 on page 22) works with the Routing Engine to provide the

following control and monitoring functions for the TX Matrix Plus router.

Chapter 2: TX Matrix Plus Hardware Component Overview
