TX Matrix Plus Router Hardware Guide

Troubleshooting the TX Matrix Plus SIBs

Problem
Solution
294
During normal operation:
All TXP-F13 SIBs, TXP-F2S SIBs, and TXP-T1600 SIBs are online.
The following alarms and LEDs indicate a problem with the SIBs:
On the craft interface, the red
An alarm occurs as shown in Table 51 on page 303.
Command output shows the SIB is
To troubleshoot the SIBs:
Check the LEDs on the craft interface:
1.
Red LED for a TXP-F13 SIB on the craft interface is on—Use the CLI to check
FAIL
the status of the TXP-F13 SIB. For information about using the display, see "TX
Matrix Plus Craft Interface Overview" on page 30.
LED is lit steadily—Remove and install the TXP-F13 SIB or TXP-F2S SIB again.
FAIL
If the LED still lights steadily, the SIB is not functioning properly. Contact your
FAIL
customer support representative.
Verify that the TXP-F13 SIBs
2.
online by issuing the
show chassis sibs
user@host> show chassis sibs
sfc0-re0:
--------------------------------------------------------------------------
Slot State
0 Online
1 Online
2 Invalid
3 Online
4 Online
5 Invalid
6 Online
7 Online
8 Online
9 Online
10 Invalid
11 Spare
12 Spare
13 Invalid
14 Invalid
15 Invalid
0/0 Online
0/2 Online
0/4 Online
0/6 Online
1/0 Online
1/2 Online
1/4 Online
1/6 Online
FAIL LED for a TXP-F13 SIB is on.
Offline .
, TXP-F2S SIBs
SIB F13 SIB F2S
command:
Type Uptime
SIB F13 4 hours, 1 minute, 56 seconds
SIB F13 4 hours, 1 minute, 39 seconds
SIB F13 4 hours, 1 minute, 56 seconds
SIB F13 4 hours, 1 minute, 39 seconds
SIB F13 4 hours, 1 minute, 56 seconds
SIB F13 4 hours, 1 minute, 39 seconds
SIB F13 4 hours, 1 minute, 56 seconds
SIB F13 4 hours, 1 minute, 39 seconds
SIB F13
SIB F13
SIB F2S 4 hours, 2 minutes, 17 seconds
SIB F2S 4 hours, 2 minutes, 15 seconds
SIB F2S 4 hours, 2 minutes, 14 seconds
SIB F2S 4 hours, 2 minutes, 13 seconds
SIB F2S 4 hours, 2 minutes, 25 seconds
SIB F2S 4 hours, 2 minutes, 24 seconds
SIB F2S 4 hours, 2 minutes, 23 seconds
SIB F2S 4 hours, 2 minutes, 22 seconds
Copyright © 2010, Juniper Networks, Inc.
, and TXP-T1600 SIBs are
