TX Matrix Plus Router Hardware Guide

Removing a TXP-CIP

328
The TXP-CIPs are located to the right of the TXP-F2S SIB card cage, below the TXP-CBs
and Routing Engines.
Each redundant TXP-CIP is hot-removable and hot-insertable. It weighs approximately
5.3 lb (2.4 kg). When the TXP-CIP is removed, the backup TXP-CIP provides redundant
connections to the active host subsystem in the TX Matrix Plus router and the active
LCC-CBs in the T1600 routers.
NOTE: If you are replacing a TXP-CIP in an operational TX Matrix Plus router,
the TX Matrix Plus router and each T1600 router in the routing matrix must
have redundant host subsystems.
To remove a TXP-CIP (see Figure 103 on page 329):
Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect
1.
the strap to one of the ESD points on the chassis.
Determine whether the TXP-CIPto be replaced is active or a backup. If the green
2.
LED on the TXP-CIP faceplateis lit, the TXP-CIP is active.
ACTIVE
Bring the TXP-CIP offline, using one of the following methods:
3.
Press and hold the ONLINE/OFFLINE
faceplate until the
OK
Issue the following CLI command.
user@host> request chassis cip offline slot 0
Verify the LED and
OK ACTIVE
4.
being removed.
NOTE: The other TXP-CIP must be online and active before you remove
the TXP-CIP being replaced.
Label each cable with its corresponding port name—for example,
5.
.
0
Disconnect all cables connected to the TXP-CIP.
6.
Loosen the captive screws at the top and bottom of the TXP-CIP faceplate.
7.
Grasp the handle on the TXP-CIP faceplate and carefully pull the TXP-CIP straight
8.
out of the chassis.
CAUTION: Be sure to slide the TXP-CIP straight within the slot to avoid
damaging the connector pins on the front of the midplane.
button located at the top of the TXP-CIP
LED is not lit.
LED is lit on the faceplate of the TXP-CIP that is not
LCC CTRL PLANE
