TX Matrix Plus Craft Interface Overview

Craft Interface Front Panel

Chassis
ID switch
cover
30
TX Matrix Plus RE-C2600 Routing Engine Overview on page 26
Troubleshooting the TX Matrix Plus Host Subsystem on page 311
Troubleshooting the TX Matrix Plus Routing Engines on page 312
Craft Interface Front Panel on page 30
LCD Modes on page 31
LCD Navigation Buttons on page 32
Alarm Cutoff/Lamp Test Button on page 32
The craft interface allows you to view status and troubleshooting information at a glance
and to perform many system control functions. It is hot-insertable and hot-removable.
The craft interface is located at the upper front of the TX Matrix Plus router.

Figure 14: Front Panel of the TX Matrix Plus Craft Interface

LCD
display
The front panel of the craft interface contains:
SFC chassis number.
Configuration (config) size.
A four-line LCD display, along with six navigation buttons. The LCD display operates
in Idle mode or alarm mode.
Yellow Minor Alarm LED, red
Alarm cutoff/lamp test
Chassis Status Master and
, , and LEDs for each TXP-F13 SIB.
OK FAIL ACT
OK and FAIL LEDs for the front and rear fan trays.
and LEDs for each power supply.
OK FAIL
Menu
Buttons Alarm LEDS
Chassis
status
LEDs
Major Critical Alarm LED.
button.
ACO/LT
Standby LEDs.
SIB-F13 Fan and
status PEM
LEDs LEDs
