TX Matrix Plus Router Hardware Guide

Chassis Status LEDs on the TX Matrix Plus Craft Interface

Related
Documentation

TXP-F13 SIB LEDs on the TX Matrix Plus Craft Interface

34
Two LEDs located in the middle of craft interface below the Alarm LEDs indicate whether
the TX Matrix Plus router is functioning as the master for the routing matrix. Table 11 on
page 34 describes the functions of the Chassis Status LEDs.

Table 11: Chassis Status LEDs on the TX Matrix Plus Craft Interface

Label Color
MASTER Green
–
STANDBY
NOTE: This LED is reserved for future use.
TX Matrix Plus Switch-Fabric Chassis Description on page 8
TX Matrix Plus Craft Interface Overview on page 30
The right side of the craft interface has three LEDs for each TXP-F13 SIB that indicate
the status of that SIB. The corresponding TXP-F13 SIB slots are labeled 0 through 15.
Table 12 on page 34 describes the functions of the TXP-F13 SIB LEDs.

Table 12: TXP-F13 SIB LEDs on the TX Matrix Plus Craft Interface

Label Color
Green
OK
–
Red
FAIL
–
Green
ACTIVE
–
State Description
On steadily The TX Matrix Plus router is functioning as the master
SFC for the routing matrix. For the A4 configuration,
this LED should always be lit when the router is
receiving power.
Off For the A4 configuration, the TX Matrix Plus router
might not be receiving power.
State Description
On steadily TXP-F13 SIB is functioning normally.
Blinking TXP-F13 SIB is coming online.
Off TXP-F13 SIB is not functioning normally.
On steadily TXP-F13 SIB has failed.
Off No faults have been detected for the TXP-F13 SIB.
On steadily TXP-F13 SIB is in active mode and actively passing
traffic.
Off TXP-F13 SIB is either offline or not actively passing
traffic.
