Replacing TX Matrix Plus Power System Components

Replacing a TX Matrix Plus Seven-Input 420-A Power Supply

Copyright © 2010, Juniper Networks, Inc.

Figure 129: Installing a TXP-F2S SIB

TX Matrix Plus TXP-F2S SIB Overview on page 17
TX Matrix Plus TXP-F2S SIB LEDs on page 19
Troubleshooting the TX Matrix Plus SIBs on page 294
TX Matrix Plus Preventing Electrostatic Discharge Damage on page 392
Replacing a TX Matrix Plus Seven-Input 420-A Power Supply on page 373
Replacing a TX Matrix Plus Seven-Input 430-A Power Supply Input Power
Tray on page 377
Replacing a DC Power Supply Cable on page 382
Removing a Seven-Input 420-A Power Supply on page 373
1.
Installing a Seven-Input 420-A Power Supply on page 375
2.
Powering On a Seven-Input 420-A Power Supply on page 376
3.

Removing a Seven-Input 420-A Power Supply

The TX Matrix Plus router has two redundant, load-sharing DC power supplies. Each
power supply is hot-insertable and hot-removable. When one power supply is powered
off or removed, the other power supply automatically assumes the entire electrical load
Chapter 22: Replacing TX Matrix Plus Hardware Components
373
