TX Matrix Plus Alarm Relay Contact Wire Specifications

Related
Documentation
444
Control Plane Connections from the TX Matrix Plus Router to the T1600 Routers on
page 58.
Connecting the TX Matrix Plus Router to a Network Device on page 158
Connecting the TX Matrix Plus Router to a Management Console or Auxiliary Device
on page 160
RJ-45 Connector Pinouts for the TX Matrix Plus Routing Engine ETHERNET Port on
page 445
RJ-45 Connector Pinouts for the TX Matrix Plus Routing Engine AUXILIARY and
CONSOLE Ports on page 446
For management and service operations, you can connect the TX Matrix Plus router to
external alarm-reporting devices through the alarm relay contacts on the TXP-CIP.
Table 66 on page 444 lists the specifications for the cables that connect to management
ports and the wires that connect to the alarm relay contacts.

Table 66: TX Matrix Plus Wire Specifications for Alarm Interfaces

Cable
Port Specification
Alarm relay Wire with gauge
contacts between
28-AWG and
14-AWG (0.08
and 2.08 mm
TX Matrix Plus Craft Interface Overview on page 30.)
Connecting the TX Matrix Plus Router to External Alarm-Reporting Devices on page 162
Maximum
Wire Supplied Length
No None
2
)
