TX Matrix Plus TXP-F13 SIB LEDs

Copyright © 2010, Juniper Networks, Inc.
Table 3: TXP-F13 SIB Slots (continued)
TXP-F13 SIB Slot TXP-F13 SIB Name
Slot 8
SIB F13 8
Slot 9
SIB F13 9
Slot 10 Unused
Slot 11 SIB F13 11
Slot 12 SIB F13 12
Slot 13 Unused
Slot 14 Unused
Slot 15 Unused
Routing Matrix with a TX Matrix Plus Router Switch Fabric and Switching Plane
Architecture on page 60
TX Matrix Plus TXP-F13 SIB LEDs on page 15
Maintaining the TX Matrix Plus SIBs on page 269
Troubleshooting the TX Matrix Plus SIBs on page 294
Troubleshooting the Switching Planes in the Routing Matrix on page 305
The TXP-F13 status LEDs (Figure 6 on page 15) are located below the
buttons. Table 7 on page 19 describes the functions of these LEDs.

Figure 6: TXP-F13 SIB LEDs

Port LEDs
Chapter 2: TX Matrix Plus Hardware Component Overview
Plane
3
–
4
–
–
–
Link Status
Rx Optical Power
ONLINE/OFFLINE
15
