Copyright © 2010, Juniper Networks, Inc.
Chapter 15: Connecting the Fiber-Optic Array Cables to the TX Matrix Plus Router
The cable management comb assembly installs on the top of the chassis and adds 17
in. (43.18 cm) to the height of the chassis.

Figure 83: Cable Management Comb Assembly

Thread the fiber-optic cables
through the labeled dividers.
CAUTION: Plastic wrap-ties can damage or crimp the fiber-optic array cables
(see Figure 84 on page 192). We recommend that you use soft band straps to
secure fiber-optic array cables.
Comb assembly
191
