TX Matrix Plus Cable Connector Pinouts
RJ-45 Connector Pinouts for the TX Matrix Plus Routing Engine ETHERNET Port
Related
Documentation
Copyright © 2010, Juniper Networks, Inc.

RJ-45 Connector Pinouts for the TX Matrix Plus Routing Engine ETHERNET

Port on page 445
RJ-45 Connector Pinouts for the TX Matrix Plus Routing Engine AUXILIARY and
CONSOLE Ports on page 446
The port on the TXP-CB labeled
Ethernet RJ-45 receptacle that accepts an Ethernet cable for connecting the Routing
Engine to a management LAN (or other device that supports management of the routing
matrix). Table 67 on page 445 describes the RJ-45 connector pinout.

Table 67: RJ-45 Connector Pinout for the TX Matrix Plus ETHERNET Port

Pin Signal
1 TX+
2 TX –
3 RX+
4 Termination network
5 Termination network
6 RX–
7 Termination network
8 Termination network
TX Matrix Plus TXP-CB Overview on page 21
Routing Engine Ports on the TXP-CB on page 23.
Connecting the TX Matrix Plus Router to a Network Device on page 158
is an autosensing 10/100-Mbps/1-Gbps
ETHERNET
