TX Matrix Plus Router Hardware Guide
Related
Documentation

Reinstalling TX Matrix Plus Components After Installing the Chassis

Reinstalling the Rear Fan Trays

144
Rack Requirements for a TX Matrix Plus Router on page 106
Tools Required to Install the TX Matrix Router Using a Lift on page 128
Reinstalling TX Matrix Plus Components After Installing the Chassis on page 144
General Safety Guidelines for M Series, MX Series, and T Series Routers on page 391
TX Matrix Plus Preventing Electrostatic Discharge Damage on page 392
TX Matrix Plus Installation Safety Guidelines on page 399
After the TX Matrix Plus router is installed in the rack, you reinstall the removed
components before cabling, booting, and configuring the router. The procedures describe
how to reinstall components in the chassis, first in the rear and then in the front:
Reinstalling the Rear Fan Trays on page 144
1.
Reinstalling the Power Supplies on page 145
2.
Reinstalling the TXP-F13 SIBs on page 147
3.
Reinstalling the Front Fan Trays on page 148
4.
5. Reinstalling the Host Subsystems on page 149
Reinstalling the TXP-F2S SIBs on page 150
6.
To reinstall the rear fan tray (see Figure 61 on page 145):
Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect
1.
the strap to one of the ESD points on the chassis.
Grasp the fan tray by its handles and insert it straight into the chassis.
2.
Tighten the captive screw on the bottom of the fan tray faceplate to secure it in the
3.
chassis, using a Phillips (+) screwdriver, number 2.
