TX Matrix Plus Router Hardware Guide

TX Matrix Plus Host Subsystem Overview

TX Matrix Plus Host Subsystem Description

Related
Documentation

TX Matrix Plus Control Board Description

20
TX Matrix Plus Host Subsystem Description on page 20
TX Matrix Plus Control Board Description on page 20
TX Matrix Plus TXP-CB Overview on page 21
TX Matrix Plus TXP-CB LEDs on page 23
TX Matrix Plus Routing Engine Description on page 25
TX Matrix Plus RE-C2600 Routing Engine Overview on page 26
TX Matrix Plus RE-C2600 LEDs on page 28
The host subsystem provides the routing and system management functions of the TX
Matrix Plus router. You can install one or two host subsystems on the TX Matrix Plus
router. A host subsystem consists of a Routing Engine installed directly into a slot in a
control board. To operate, each host subsystem functions as a unit; the Routing Engine
requires the corresponding control board, and vice versa.
NOTE: We recommend that you install two host subsystems for redundant
protection. If you install only one host subsystem, we recommend that you
install it in slot
CB0
TX Matrix Plus Control Board Description on page 20
TX Matrix Plus TXP-CB Overview on page 21
TX Matrix Plus Routing Engine Description on page 25
TX Matrix Plus RE-C2600 Routing Engine Overview on page 26
You can install up to two control boards in the TX Matrix Plus Router. Control boards
install into the upper front of the chassis in the slots labeled
and ). A Routing Engine installs directly into a slot on each control board. The
CB-0 CB-1
control boards can not function if a Routing Engine is not present.
Each control board works with the Routing Engine to provide the following control and
monitoring functions for the TX Matrix Plus router:
Determining Routing Engine mastership
Controlling power and reset for the other TX Matrix Plus components
Monitoring and controlling fan speed
Monitoring system status.
.
Copyright © 2010, Juniper Networks, Inc.
and (referred to as
CB0 CB1
