I/O Processors

I/O processors of the Intel RAID Controller SRCU32 are represented in the physical configuration
window in Figure 81 and in the table below. Each processor controls one I/O channel.
Table 21. I/O Processor Icons
Item Description
SCSI processor
SE (single ended)
SCSI processor
LVD/SE (low voltage differential / single ended)
FC processor
FC AL (fibre channel arbitrated loop)
