- Page 1 SRCZCR Hardware Installation and User’s Guide, Version 1.1.5 October 2002 Order Number: C18225-002...
- Page 2 Except as permitted by such license, no part of this document may be reproduced, stored in a retrieval system, or transmitted in any form or by any means without the express written consent of Intel Corporation.
-
Page 3: Table Of Contents
Contents Getting Started Using the User Documentation Set ....................5 1.1.1 Document Formats ...................... 6 About This Guide...........................6 Customer Support Contact Information ..................6 Regulatory and Certification Information ..................7 1.4.1 Product Regulatory Compliance .................. 7 1.4.2 Product Safety Compliance ..................7 1.4.3 Product EMC Compliance ...................7 1.4.4... - Page 4 Tables Configurable Disk Drive SCSI Parameters ................. 16 Configurable I/O Controller SCSI Parameters ................16 Hardware Architecture Features ....................17 Electrical Specifications ......................17 Environmental Specifications ..................... 18 Supported SCSI Device Standards .................... 19 RAID Controller Drive Maximum Limitations (SRCZCR) ............22 Hardware Installation and User’s Guide...
-
Page 5: Getting Started
Intended Audience This documentation is intended for users who are experienced in configuring computer ® systems with new add-in cards or have had previous experience with Intel Integrated RAID (IIR) Controllers. Read and adhere to all warnings, cautions, and notices in this guide and the other documents in the user documentation set supplied with this product. -
Page 6: Document Formats
Clustering is applicable only for those RAID controllers that support this feature. See the Hardware Guide to determine if clustering is supported. ® The Intel Integrated RAID Controller Clustering Guide, or Clustering Guide, describes how to set up clustering configurations using IIR Controllers and IIR controller software. -
Page 7: Regulatory And Certification Information
Getting Started Regulatory and Certification Information This card is intended for use in UL Listed computers or equivalent, that have instructions Note: detailing installation. 1.4.1 Product Regulatory Compliance The IIRZN0CHXX (SRCZCR) RAID add-in card, when correctly integrated per this guide, complies with the following safety and electromagnetic compatibility (EMC) regulations. -
Page 8: Product Regulatory Compliance Markings
Getting Started 1.4.4 Product Regulatory Compliance Markings The IIRZN0CHXX (SRCZCR) RAID controller is marked with the following regulatory markings: Marking Description LISTED ACCESSORY E139761 UL Listed Accessory mark for USA and Canada CE mark for European Union C-Tick mark for Australia and New Zealand N232 Canada ICES Mark Korea MIC Mark... - Page 9 Getting Started If you make any modification to the equipment not expressly approved by Intel, you could void your authority to operate the equipment. Any changes or modifications not expressly approved by the grantee of this device could void the user’s authority to operate the equipment. The customer is responsible for ensuring compliance of the modified product.
- Page 10 1.4.5.5 RRL (Korea) These products have been tested in accordance to, and complies with Korean RRL certification requirements. IIRZN0CHXX E-G016-01-5788 (A) Intel Corporation Refer to Date Code on Product Solectron Technology Sdn. Bhd. / Malaysia Hardware Installation and User’s Guide...
-
Page 11: Warnings And Cautions
Getting Started Warnings and Cautions This guide and all associated guides in the user documentation set (the Quick Start Guide, the Hardware Guide, and the Software Guide) should be used by qualified technical personnel with experience installing and configuring PCI adapter cards. Read and adhere to all warnings, cautions, and notices in this guide and all the guides in the user documentation set supplied with this product. - Page 12 Getting Started Hardware Installation and User’s Guide...
-
Page 13: Hardware Installation
Hardware Installation Hardware Installation About this Chapter This chapter provides information on installing the IIR controller, programming the Flash memory, and general SCSI termination information. Installation Procedures Warning: Do not attempt to insert your RAID controller into any non RAIDIOS-enabled PCI slot. -
Page 14: Installing The Iir Controller
Hardware Installation Figure 2-1. IIR Controller Component Layout 167mm (6.57 inches) I/O Processor DS2A1 SDRAM J1B1 Flash Memory 64Bit 3.3 Volt PCI Interface (Requires a RAIDIOS-enabled PCI slot) 2.2.2 Installing the IIR Controller 1. Power-off the computer system. 2. Disconnect power cord(s) and remove the system cover. 3. -
Page 15: Programming The Flash Memory
Hardware Installation Figure 2-2. Installing the IIR Controller into a Computer System RAIDIOS-ENABLED PCI Programming the Flash Memory The IIR controller normally comes ready to be installed into the computer motherboard immediately. However, you may need to reprogram the RAID firmware that is located in the flash memory of the IIR controller. -
Page 16: Configurable Disk Drive Scsi Parameters
Hardware Installation Configurable Disk Drive SCSI Parameters When a SCSI hard disk drive is initialized the first time by the RAID controller, its SCSI parameters are automatically set to their optimal settings. Most settings are set automatically and can not be configured manually. To view or configure disk drive SCSI parameters from the Storage Console, choose Advanced Setup Configure Physical Devices... -
Page 17: Hardware Specifications And Features
Hardware Specifications and Features Hardware Specifications and Features This chapter covers all the hardware specifications associated with the IIR controller and its components. Section 3.5 covers optional RAID features that are supported by the RAID Software Suite. The accompanying Software Guide covers all implemented software features. -
Page 18: Operating System Support
Hardware Specifications and Features Table 3-3. Environmental Specifications Attribute Condition Operating Temperature 0° C to +55° C Storage Temperature -40° C to +70° C Height: 56 mm (2.20 inches) Form Factor (physical dimensions) Length: 167 mm (6.57 inches) Operating System Support The following operating systems are fully validated and supported: •... -
Page 19: Supported Hard Drive Technology
Hardware Specifications and Features The SRCZCR firmware supports the following SCSI controllers on the motherboard: • SCSI Ultra160 — Adaptec* AIC-7899x dual-channel Ultra160 SCSI controller — Adaptec AIC-7892x single-channel Ultra160 SCSI controller • SCSI Ultra320 — Adaptec AIC-7901 single-channel Ultra320 SCSI controller —... -
Page 20: Support For Non-Hard-Disk-Drive Scsi Devices (Non-Direct-Access Devices)
Hardware Specifications and Features Table 3-4. Supported SCSI Device Standards Maximum Cable Length (meters) Adapter Maximum SCSI Drive Speed Bus Width Devices per SCSI Standard (MB/Sec) (Bits) Single- Channel Ended Wide Ultra 2 Ultra160 (Ultra 3) Ultra320 Notes: 1. May be exceeded in Point-to-Point and engineered specific applications. 2. -
Page 21: Optional Features
Hardware Specifications and Features Warning: †† The SRCZCR adapter, with firmware 2.34.yy-Rzzz, is not compatible with all previous controllers and firmware versions. Do not attempt RAID Array Drive Roaming between RAID controllers that are not compatible with the SRCZCR controller. Unpredictable behavior may include, but is not limited to, data loss or corruption. -
Page 22: Raid Controller Drive Maximum Limitations (Srczcr)
Hardware Specifications and Features RAID firmware limits the controller to a maximum of 30 host drives (RAID volumes) per controller. There is a minimum of at least one host drive per array drive. A host drive can only be associated with (or reside on) a single array drive. Like array drives, host drives can reside on hard disk drives that are isolated to a single channel or span both of the channels of the RAID controller. -
Page 23: A Flash Memory Programming
The current firmware file can be found on the RAID Software Suite CD-ROM. To get the latest firmware for the IIR controller, visit our website at: http://support.Intel.com. The Firmware Update option is not available when StorCon is accessing the IIR Note: Controller remotely. -
Page 24: Firmware Recovery Procedure Via Flash Recovery Utility (Fru)
Flash Memory Programming Warning: Do not interrupt the update process to avoid damaging the firmware image in the Flash. If the firmware is interrupted you will need to follow the firmware recovery process in the next section. After StorCon indicates that the update is complete, press any key. 9. - Page 25 Flash Memory Programming 2. Change your computer’s BIOS setting so that your system boots from the CD-ROM. 3. Use the RAID Software Suite CD-ROM to flash the firmware. a. Boot the computer with the bootable RAID Software Suite CD-ROM that contains the version of the RAID firmware that you wish to recover.
- Page 26 Flash Memory Programming Hardware Installation and User’s Guide...
-
Page 27: Index
Index Index adapter hardware architecture features 17 system requirements 13 disk drive connectivity 18 flash memory programming 15 recovering the firmware 24 installation raid adapter 14 warnings and cautions 11 raid adapter hardware features 17 hardware requirements 13 installation 14 intallation procedures 13 optional features 21 system requirements 13...
