Compatible Intel RAID Controllers
This Intel RAID Controller SRCU32 is compatible with other Intel RAID Controllers SRCU32 and
SRCMR and allows for array roaming.
NOTE
Compatible refers to the ability of the Intel RAID Controller SRCU32 to read the RAID
configuration information located on hard drives that are members of RAID Arrays that have been
created on compatible adapters. Thus RAID Arrays created on compatible adapters are
interchangeable between the adapters (Array Roaming).
Optional RAID Features Implemented in the Intel RAID
Controller SRCU32
Adapter Device Limitation Support
RAID Arrays contain
Host Drives (at least 1 and up to 16 maximum)
Hard Drives up to 30 maximum spanning both channels (all host drives that are created on
an existing RAID Array will have their capacity evenly distributed across all member hard
drives of the RAID Array)
Host Drives
Can span across both channels
Can not span across RAID Arrays
Table 8.
Disk, Volume, and Array Limitations
Adapter Device Limitations
Per Adapter
Max
Hard Drives
30
RAID Arrays
16
Host Drives
16
Note:
1. Each Host Drive can only be associated with one RAID Array.
2. To create a new RAID Array you must initially create a Host Drive selecting the hard drives (that are available
and not already members of a RAID Array) that you wish to be members of the new RAID Array.
PCI Hot Plug
The SRCU32 adapter supports PCI Hot Plug under the following OS's:
Windows 2000 Advanced Server SP2, Windows 2000 Server, Windows 2000 Professional
NetWare 5.1 SP2a
This IIR controller supports the PCI Hot Plug functionality for the Hot Replacement of an adapter.
Hot Replacement assumes that the drivers for the adapter being replaced are already loaded.
Getting Started
Per RAID Channel
Min
Max
Min
15
15
16
Per RAID Array
Per Host Drive
Max
Min
Max
30
1
30
2
1
1
16
1
Min
33
