General Installation Notes
For detailed hardware requirements, specifications, and installation procedures, specific to the Intel
RAID Controller SRCU32, refer to Chapter 2.
Minimum Hardware Requirements
NOTE
The Intel RAID Controller SRCU32 will work in a 32-bit, 33 or 64 MHz PCI slot; however, a 64-bit
66 MHz slot is recommended for maximum performance.
Computer with CD-ROM drive (not attached to the Intel RAID Controller SRCU32).
Computer must be on the supported hardware list (for example, Intel SCB2 server board).
One available PCI slot. See note above.
PCI 2.2 compliant System BIOS.
SCSI hard drive(s) (the minimum required to meet the desired RAID level).
Minimum Software Requirements
RAID Software Suite CD-ROM
10 MB of hard drive space
RAID Driver Installation Diskette for Linux
Linux Red Hat 7.x Installation CD-ROMs
Root access on the Linux server
Installing Red Hat Linux 7.x on a RAID Volume
(Host Drive)
To install Red Hat Linux 7.x on to a host drive, first create the appropriate driver disk from the Intel
RAID Controller SRCU32 CD-ROM:
1. In the system BIOS, ensure that the computer is set to boot off of the CD-ROM drive.
2. Place the RAID Software Suite CD-ROM in the CD-ROM drive and boot the system.
3. Select the option to make diskettes.
4. Select Red Hat Linux and the appropriate driver for the system. When driver disk is created,
follow the procedure below to create a host drive to install to.
5. Ensure the Intel RAID Controller SRCU32 is installed in the system and is connected to drives
on which you intend to create a host drive.
6. Boot the system and when prompted press <Ctrl> + <G> to enter StorCon. Create a single host
drive from the selected disks.
7. For more information on creating host drives using the StorCon, see Chapter 7, Configure New
Host Drive.
56
Intel RAID Controller SRCU32 User's Guide
