Removing the SDRAM

1. With the thumbs on the DIMM clips, swing the clips from the close position to the open
position.
2. Grasp the corners of the DIMM with both hands and firmly pull from the DIMM connector.
Install the Intel RAID Controller SRCU32 in the Intel
Server Board
The RAID firmware has already been programmed into the memory. Prior to installing the Intel
RAID Controller SRCU32 into the computer, an approved memory module must be installed in the
controller. For a list of approved memory modules refer to:
http://support.intel.com/support/motherboards/server/
CAUTION
Contact the RAID vendor for a list of approved memory modules.
Getting Started

Figure 7. Installing the SDRAM

®
23
