The Controller Events Window

The controller events window shows the history of events (since the log was last cleared). The
table below illustrates the severity of events.
Table 29. Event Window Icons
Event Icon
The first column in the event window contains icons representing the severity of the event. The
second column lists how often the event occurred. Note that some events may occur often. The
next column lists the date and the time when the event occurred. The last column describes the
event. At the bottom of the window there is the Settings button. Here you can change the polling
interval and enable the auto save function. Logs that are not saved on the hard drive are lost when
the system is reset. The auto save function saves the current log in the time intervals selected there.
The default name for this logfile is "srcevt.evt." The "Save As" button allows you to write the
contents of the event log to a specific file on the hard drive. The Load button loads an older event
log and displays it. The last two buttons delete the log file and clear the event buffer.
162
Figure 104. Controller Events Window Icon
Event Description
Information: This event is non critical. It occurs, for example, at the completion of an
array build.
Warning: This event is critical. It occurs, for example, if an array drive's state changes
from ready to fail.
Error: An error has occurred. This event could be a drive failure.
Intel RAID Controller SRCU32 User's Guide
